MODEL TCM-3700-2 0109-001 218 㔚᳇೙ᓮㇱ ELECTRICAL SECTION Fig.11-12 ᯏ᪾ᑫࠅ 1 Miscellaneous Parts-1 TCM-3700-2 Fig.11-12 73 73 71 32 31 30 29 28 27 26-1 32 31 30 45 44 43 55 54 53 50 49 48 47 22 21 32 31 30 29 28 27 26 25 23 2…

100%1 / 274
MODEL TCM-3700-2
0109-001
217
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
11-11
1 630 085 7535 BOX 1 739DD-01V-001
2 630 051 6173 HANDLE 1 739DD-01D-018
3 411 141 4503 WASHER V 8X17X1.6 2 FW8
4 411 141 3100 WASHER SPR 8 2 SW8
5 630 000 8005 BOLT,HEX-SCT 2 M8X16
6 630 086 8395 UNIT,DISPLAY 1 #UT3-E1AE-D-M 739DD-01D-014
6 -1 630 085 7580 PANEL 1 739DD-01V-008
6 -2 411 119 1909 WASHER V 3X7X0.5 4 FW3 F
6 -3 411 086 4408 WASHER SPR 3 4 SW3 F
6 -4 411 040 6202 SCR PAN 3X10 4 M3X10 PAN
7 411 140 8304 SCR BIN 4X10 8 M4X10 BIN
10 630 058 5728 PANEL 1 739DD-01V-002
11 630 033 4609 SWITCH,BUTTON 1 PB2 739DD-01D-001
12 630 033 4586 DISPLAY ELEMENT 1 LED8 739DD-01D-002
13 630 033 4593 ACCESSORY,SW 1 739DD-01D-003
14 630 066 7042 SWITCH,BUTTON 1 PB4 739DD-01D-004
16 630 000 2713 SWITCH,BUTTON 1 PB14(LED9) 739DD-01D-006
17 630 000 0382 ACCESSORY,SW 1 739DD-01D-009
18 630 000 2515 SWITCH,BUTTON 2 PB18, PB19 739DD-01D-005
19 630 000 2713 SWITCH,BUTTON 2 PB15(LED10), PB22(LED11)
739DD-01D-006
20 630 000 0382 ACCESSORY,SW 2 739DD-01D-009
21 630 000 2508 SWITCH,BUTTON 2 PB16, PB17 739DD-01D-012
22 630 000 0382 ACCESSORY,SW 2 739DD-01D-009
23 630 007 6066 SWITCH,BUTTON 1 PB20 739DD-01D-007
24 630 007 6066 SWITCH,BUTTON 1 PB21 739DD-01D-007
25 630 000 0382 ACCESSORY,SW 1 739DD-01D-009
27 630 000 2744 SWITCH,BUTTON 1 PB23(LED12) 739DD-01D-008
28 407 035 4704 LED SLP-721F 1 LED13 739DD-01D-011
29 411 140 8304 SCR BIN 4X10 5 M4X10 BIN
30 630 000 5059 COUNTER 1 MCT 739DD-01D-013
31 630 085 7566 COVER 1 739DD-01V-006
32 411 113 9109 SCR TRS 5X10 9 M5X10 TRS
41 630 057 8010 SUPPORT 1 739DD-01V-004
42 630 051 6180 BUSH,BEARING 2 739DD-01D-015
43 630 052 3041 BRACKET 1 739DD-01V-003
44 630 051 5923 PIN,LOCATE 2 739DD-01V-005
45 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
46 411 141 3001 WASHER SPR 6 4 SW6
47 630 000 7886 BOLT,HEX-SCT 4 M6X16
48 630 051 6166 MECH PARTS(DRYMET WASHER) 1 739DD-01D-016
49 630 051 6159 MECH PARTS(7LOBE KNOB) 1 739DD-01D-017
50 630 041 6770 COLLAR 1 739DD-01V-007
51 630 000 8944 SET SCREW 1 M5X6 SET
52 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
53 411 141 3001 WASHER SPR 6 4 SW6
54 630 000 7886 BOLT,HEX-SCT 4 M6X16
55 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
56 411 141 3001 WASHER SPR 6 4 SW6
57 630 000 7893 BOLT,HEX-SCT 4 M6X20
MODEL TCM-3700-2
0109-001
218
㔚᳇೙ᓮㇱ ELECTRICAL SECTION
Fig.11-12 ᯏ᪾ᑫࠅ 1 Miscellaneous Parts-1
TCM-3700-2
Fig.11-12
73
73
71
32
31
30
29
28
27
26-1
32
31
30
45
44
43
55
54
53
50
49
48
47
22
21
32
31
30
29
28
27
26
25
23
24
97
96
95
92
93
92
93
92
87
88
89
91
69-3
69-2
69-1
10-4
10-3
10-2
10-1
10-6
10-5
10-1
E
14
13
12
59
58
57
19-4
19-3
19-2
19-1
19-6
A
B
C
102
101
6-1
6
6-2
6-3
5-1
5-2
5-3
5
103
104
D
19-1
19-5
56
14
13
12
14
13
12
11-3
11-2
15-3
15-2
15-1
15
11-1
A
68
66
61
61-1
62-1
62
65
57
63
63-1
64
B
4
3
2
1
E
C
D
69
See Fig.11-14
Key No.7
32
31
30
41
42
50
49
48
10-4
4
3
2
1
10-3
10-2
10-1
10-6
10-5
10-1
46
52
51
25
21
22
23
24
72
MODEL TCM-3700-2
0109-001
219
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
11-12
1 630 091 1541 UNIT,DRIVER 2 SMD2(R1), SMD3(R2),
#SGDM-50ADA-R 739FB-01D-019
2 411 088 1702 WASHER V 5X10X1 8 FW5 F
3 411 008 2109 WASHER SPR 5 8 SW5 F
4 411 043 6803 SCR PAN 5X12 8 M5X12 PAN
5 630 091 1558 UNIT,DRIVER 1 SMD4(X), #SGDM-30ADA-R
739FB-01D-021
5 -1 411 088 1702 WASHER V 5X10X1 4 FW5 F
5 -2 411 008 2109 WASHER SPR 5 4 SW5 F
5 -3 411 043 6803 SCR PAN 5X12 4 M5X12 PAN
6 630 094 7779 UNIT,DRIVER 1 SMD5(Y), #SGDM-15ADA-R
739FB-01D-022
6 -1 411 119 2104 WASHER V 4X9X0.8 4 FW4 F
6 -2 411 008 1706 WASHER SPR 4 4 SW4 F
6 -3 411 003 0001 SCR PAN 4X12 4 M4X12 PAN
10 -1 630 051 5763 WIRE PARTS 4 739FB-01D-101
10 -2 411 119 2104 WASHER V 4X9X0.8 4 FW4 F
10 -3 411 008 1706 WASHER SPR 4 4 SW4 F
10 -4 411 043 5004 SCR PAN 4X8 4 M4X8 PAN
10 -6 411 036 8609 SCR PAN+SW+W 5X12 12
11 -1 630 053 2654 UNIT,DRIVER 1 PMD19(TR), #AK-BX551PV-SAT8
739FB-01D-082
11 -2 630 051 6555 UNIT,DRIVER 2 PMD101(CVW1), PMD102(CVW2),
#AK-BX501V-SAT4 739FB-01D-018
11 -3 630 066 0906 UNIT,DRIVER 2 PMD104(BPC), PMD100(PWC),
#AK-BX22-SAT1 739FB-01D-152
12 411 119 2104 WASHER V 4X9X0.8 10 FW4 F
13 411 008 1706 WASHER SPR 4 10 SW4 F
14 411 042 3001 SCR PAN 4X10 10 M4X10 PAN
15 630 049 0626 UNIT,POWER 1 PSU6, PWS15A-5A 739FB-01D-081
15 -1 411 119 1909 WASHER V 3X7X0.5 2 FW3 F
15 -2 411 086 4408 WASHER SPR 3 2 SW3 F
15 -3 411 042 0703 SCR PAN 3X8 2 M3X8 PAN
19 -1 630 051 5763 WIRE PARTS 2 739FB-01D-101
19 -2 411 119 2104 WASHER V 4X9X0.8 2 FW4 F
19 -3 411 008 1706 WASHER SPR 4 2 SW4 F
19 -4 411 043 5004 SCR PAN 4X8 2 M4X8 PAN
19 -6 411 036 8609 SCR PAN+SW+W 5X12 8
21 630 057 9017 SUPPORT 2 739FB-01V-004
22 630 001 0220 WASHER 4 BW5
23 411 141 6705 WASHER SPR 5 4 SW5
24 630 000 7756 BOLT,HEX-SCT 4 M5X12
25 630 057 9000 PANEL 2 739FB-01V-003
26 630 096 2536 P.C.B,MOUNT(MEKAHAI) 1 U942*002*0000 739FB-01U-001
26 -1 630 096 2741 P.C.B,MOUNT(MEKAHAI) 1 U943*002*0003 739FB-01U-004
27 411 119 1909 WASHER V 3X7X0.5 8 FW3 F
28 411 086 4408 WASHER SPR 3 8 SW3 F
29 411 162 1604 SCR PAN 3X20 8 M3X20 PAN
30 630 001 0220 WASHER 8 BW5
31 411 141 6705 WASHER SPR 5 8 SW5
