P-199-001e - 第257页
MEMO
MODEL TCM-3700-2
0109-001
254
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
12-4
55 -4 411 042 3001 SCR PAN 4X10 4 M4X10 PAN
55 -6 630 084 9233 CORD 1 739DB-01D-900
56 411 113 9109 SCR TRS 5X10 37 M5X10 TRS
71 630 084 4719 COVER 1 739R--01B-137
72 411 113 9109 SCR TRS 5X10 4 M5X10 TRS
73 630 085 4602 COVER 1 739R--01B-140
74 411 113 9109 SCR TRS 5X10 4 M5X10 TRS
75 630 084 4740 COVER 1 739R--01B-141
76 411 051 2804 SCR TRS 4X8 4 M4X8 TRS
81 630 075 8085 BRACKET 3 739R--01B-139
82 630 070 3061 MOTOR,AC 3 FAN8, FAN9, FAN10, MRS16-BUL
739FB-01D-800
83 630 074 6853 ACCESSORY,MOT-M (FILTER) 3 739FB-01D-802
85 630 068 4292 ACCESSORY,MOT-M 3 739FB-01D-801
86 411 140 7406 SCR FLT 5X20 12 M5X20 FLT
87 411 088 1702 WASHER V 5X10X1 12 FW5 F
88 411 008 2109 WASHER SPR 5 12 SW5 F
89 411 118 8503 NUT HEX 5 12 M5 F
91 411 140 6508 SCR PAN 5X20 12 M5X20 PAN
92 411 088 1702 WASHER V 5X10X1 12 FW5 F
93 411 008 2109 WASHER SPR 5 12 SW5 F
94 411 118 8503 NUT HEX 5 12 M5 F
96 411 141 4107 WASHER V 5X10X1 6 FW5
97 411 141 6705 WASHER SPR 5 6 SW5
98 630 000 7749 BOLT,HEX-SCT 6 M5X10
101 630 081 8376 COVER 3 739R--01B-142
101 -1 630 086 2317 MECH PARTS (MAGNET) 12 739R--01H-017
102 630 081 8383 COVER 1 739R--01B-143
102 -1 630 086 2317 MECH PARTS (MAGNET) 4 739R--01H-017
MEMO
MODEL TCM-3700-2
0109-001
256
49
54
55
56
50
51
52
53
74
73
72
71
66
78
77
79
80
75
76
36
36
40
41
42
43
44
45
46
47
39
36
1
27
28
14
15
17
16
18
19
20
17
11
12
13
3
2
77
81
4
5
6
35
30
31
32
33
36
30
18
19
20
35
36
31
32
33
34
34
23
24
7
9
10
22
21
8
25
23-1
23
26
26
16
16
16
62
63
64
65
57
50
61
58
59
60
TCM-3700-2
Fig.12-5
ࠞࡃㇱ COVER SECTION
Fig.12-5 ೨ᚺ Front Cover
