C-29 DI list (Co ntinued) Area Displ ayed as Sensor na me 2030 Small CST Detect Elevator cassette check sen sor 2031 UV N2 Low Lim UV cle an air fl ow rate s ensor 2032 Upper Arm FRONT Upper arm FRONT sensor 2033 Upper A…
C-28
4-1. I/O Check
Summary of this section
This section describes the ways to check the machine abnormalities by
individually operating the various sensors and solenoid valves.
If any abnormality is found in a solenoid valve or sensor during check, contact
your DISCO Service Office.
DI list
Area Displayed as Sensor name
0000 Thermal Switch
Thermalswitchintheelectricalbox
0006 UPS Backup
Uninterrupted power supply unit:
backup output
0007 UPS Battery
Uninterrupted power supply unit:
low-battery output
1040 X Water Leakage
X-axis leakage detector
1042 ST Water Leakage
Spinner leakage detector
1043 T Water Leakage
θ -axis leakage detector
2000 Ment Switch
Maintenance switch
2001 Spindle Status
Spindle power
2002 Driver Status
Axis driver power
2003 Main Cont.
Main contactor
2004 Spindle Cont.
Spindle driver contactor
2005 Servo Cont.
Servo driver contactor
2006 Pulse Cont.
Pulse driver contactor
2007 Energy Saving
Energy saving relay power
2009 Cover Elevator
Elevator section cover safety switch
2010 Cover Inspect
Inspection cover safety switch
2012 EL Obst PGV
EL obstruction detector sensor PGV arm
2013 EL Obst OHT
EL obstruction detector sensor OHT
2015 Facility Drain
Exhaust level
2018 W. Cover Z1
Wheel cover Z1
2021 W. Cover Z2
Wheel cover Z2
2024 Frame CENTER
Frame centering stage: Workpiece
presence/absence center sensor
2025 Frame REAR
Frame centering stage: Workpiece
presence/absence rear sensor
2026 Work CST FRONT
Workpiece presence/absence front sensor
2027 Work CST REAR
Workpiece presence/absence rear sensor
2028 Cassette Detect
Elevator cassette presence/absence
sensor
2029 Insp. CST Detect
Inspection cassette presence/absence
sensor
C-29
DI list (Continued)
Area Displayed as Sensor name
2030 Small CST Detect
Elevator cassette check sensor
2031 UV N2 Low Lim
UV clean air flow rate sensor
2032 Upper Arm FRONT
Upper arm FRONT sensor
2033 Upper Arm REAR
Upper arm REAR sensor
2034 Upper Arm UP
Upper arm UP sensor
2035 Upper Arm DOWN
Upper arm DOWN sensor
2036 L arm Up-c UP
Lower arm upper cylinder UP sensor
2037 L arm Up-c DOWN
Lower arm upper cylinder DOWN sensor
2038 L arm Lo-c UP
Lower arm lower cylinder UP sensor
2039 L arm Lo-c DOWN
Lower arm lower cylinder DOWN sensor
2042 P.P Clamp OK
Push-pull clamp OK sensor
2043 P.P Clamp NG
Push-pull clamp NG sensor
2044 Ionizer Alarm (U)
Ionizer alarm UP
2045 Ionizer Alarm (L)
Ionizer alarm DOWN
2046 Ionizer A. Spare
Ionizer spare alarm
2047 Ionizer A. Spare
Ionizer spare alarm
2048 Coolant Water Z1
Wheel coolant water 1 flow sensor
2049 Coolant Water Z2
Wheel coolant water 2 flow sensor
2050 Water Cas Overflow
Water case overflow
2051 S/T UP
Spinner table UP sensor
2052 S/T DOWN
Spinner table DOWN sensor
2053 NCS Cover OPEN Z1
Noncontact setup cover OPEN sensor Z1
2054 NCS Cover CLOSE Z1
Noncontact setup cover CLOSE sensor Z1
2055 NCS Cover OPEN Z2
Noncontact setup cover OPEN sensor Z2
2056 NCS Cover CLOSE Z2
Noncontact setup cover CLOSE sensor Z2
2160 Arm Cover FRONT
Arm section cover FRONT sensor
2161 Arm Cover REAR
Arm section cover REAR sensor
2162 Frame FRONT
Centering frame FRONT sensor
2163 Cassette Detect F
Cassette presence/absence kinematic pin
FRONT sensor
2164 Cassette Detect R
Cassette presence/absence kinematic pin
RIGHT sensor
2165 Cassette Detect L
Cassette presence/absence kinematic pin
LEFT sensor
2166 Cov-Lock FRONT Cut
Cut cover (splash cover) left front lock
cylinder
2167 Cov-Lock REAR Cut
Cut cover (splash cover) left rear lock
cylinder
2168 Cov-Lock FRONT Han
Arm section cover right front lock cylinder
2169 Cov-Lock REAR Han
Arm section cover right rear lock cylinder
C-30
DI list (Continued)
Area Displayed as Sensor name
2171 UV PLATE R UP
UV plate upper right sensor
2172 UV PLATE R DN
UV plate lower right sensor
2173 UV PLATE L UP
UV plate upper left sensor
2174 UV PLATE L DN
UV plate lower left sensor
2175 UV WORK
UV section workpiece presence/absence
sensor
2176 Low Arm FRONT
Lower arm FRONT sensor
2177 Low Arm REAR
Lower arm REAR sensor
