C-51
6-1. Deleting Device Data
Procedures for deleting device data
Step No.
Do This
1
Press the <F6> button on the ENGINEERING MAINTENANCE
screen [screen 7.0].
- The DEVICE DATA MAINTENANCE screen is called up.
[1]
[3]
[2]
[4]
2
At [2], specify the directory in which the device data to delete is
stored.
3
In the area [1], specify the device data to delete.
- The background of the selected device data becomes blue.
- You can select more than one device data.
4
Press the <F1> button.
5
The message, "All the data chosen is deleted. Is it all right?" is
displayed.
6
If you agree to delete them, press the <OK> button.
- If you want to abandon, press the <Cancel> button.
7
When the <OK> button is pressed, device data selected at [1]
will be deleted from the directory specified at [2]. The deleted
device data is no more displayed in the area [1].
- When the <Cancel> button is pressed, the screen display returns
to the DEVICE DATA MAINTENANCE screen. In this case,
however, the machine retains what you selected in the step 3. If
you want to cancel these selections, select those again, then
your selection will be cleared.
C-52
6-2. Moving Device Data
Procedures for moving device data
Step No.
Do This
1
Press the <F6> button on the ENGINEERING MAINTENANCE
screen [screen 7.0].
- The DEVICE DATA MAINTENANCE screen is called up.
[1]
[3]
[2]
[4]
2
At [2], specify the directory in which the device data to move is
stored.
3
At [3], specify the directory to which you want to move the
device data.
4
In the area [1], specify the device data to move among those
listed.
- The background of the selected device data becomes blue.
- You can select more than one device data.
5
Press the <F2> button.
6
The message, "All the data with which it is chosen in Directory
[2] is moved to Directory [3]. Is it all right? " is displayed.
7
If you agree to move them, press the <OK> button.
- If you want to abandon, press the <Cancel> button.
C-53
Procedures for moving device data (Continued)
Step No.
Do This
8
When the <OK> button is pressed, the device data selected in the
step 4 will move to the directory specified at [3].
- The screen display returns to the root directory.
- If there is the device data having the same device data No. as
the one you select, the device data will not move.
- When the <Cancel> button is pressed, the screen returns to the
DEVICE DATA MAINTENANCE screen. In this case,
however, the machine retains what you selected in the step 4. If
you want to cancel the selection, select those again, then your
selection will be cleared.
