D-18
Error with a code beginning with "A"
Error codes beginning with the letter A represent alignment-related errors.
Please refer to the section 2-6, [Remedies for Alignment-Related Errors]
regarding the way to handle the error.
Error Code Message
A0531 Not found macro target.
A0532 Not found micro target.
A0533 Alignment time limit over.
A0534 Not found index check target.
A0535 Index check Y position error. (Y)
A0536 Index check X position error. (X)
A0537 Angle between channels error.
A0538 Theta adjustment retry over.
A0539 This work has been cut.
A0541 ANGLE: Slice level error.
A0542 ANGLE: Chip number is not enough.
A0543 ANGLE: Retry over.
A0551 The work thickness is thicker.
A0552 Focus maintenance has not been done.
A1164 Y axes will get near too much.
D-19
Error with a code beginning with "K"
Error codes beginning with the letter K represent errors related to kerf check.
Please refer to the section 2-7, [Remedies for Kerf Check-Related Errors]
regarding the way to handle the error.
Error Code Message
K0038 Kerf check: Not found.
K0039 Kerf check: Off center.
K0040 Kerf check: Too wide.
K0041 Kerf check: Too narrow.
K0042 Kerf check: Chipping size.
K0043 Kerf check: Chipping area.
K0044 Kerf check: Target not found.
K0045 Kerf check: Target position error.
K0046 Kerf check: Too wide. (Center to Chipping)
K0047 Kerf check: Too wide. (Include chipping)
K0048 Could not find kerf center.
K0049 Kerf center position error.
D-20
Error with a code beginning with "X"
Error codes beginning with the letter X represent axis-related errors.
Please refer to the section 2-8, [Remedies for Axis-Related Errors] regarding
the rule of error code and detailed remedies.
Error Code Message
X•••0
-axis unrecoverable error. Restart the machine.
X•••1
-axis unknown error.(…..Reinitialize.)
X•••2
-axis servo error. Restart the machine.
X•••3
-axis CW end error.(…..Reinitialize.)
X•••4
-axis CCW end error.(…..Reinitialize.)
X•••5
-axis vibration error (near).(…..Reinitialize.)
X•••6
-axis vibration error (far).(…..Reinitialize.)
X•••7
-axis position error.(…..Reinitialize.)
X•••8
-axis scale retry error.(…..Reinitialize.)
Error with a code beginning with "O"
Error codes beginning with the letter O represent errors caused by other
reasons.
Please refer to the section 2-9, [Remedies for Other Errors] regarding the way
to handle the error.
Error Code Message
O0516 Workpiece in cassette.
O0518 Cassette switch turned OFF.
O0519 Remove the workpiece at W/T.
O0520 Remove the workpiece at C/T.
O0522 Remove the workpiece at S/T.
O1028 Remove the workpiece at Upper Arm.
O1029 Remove the workpiece at Lower Arm.
O1036 Inspection cassette switch turned OFF.
