D-46
E1032 : Inspection cover sensor error.
Error code
E1032
Message
Inspection cover sensor error.
What was
detected
There was an input to the cover switch of the inspection cover.
During what
operation it
occurred
While the elevator axis vertically moves.
State after
detection
The elevator axis will immediately stop.
Phenomenon Probable causes Remedy Reference
What to do
The error is issued
even though the
cover is closed.
The cover sensor is
defective.
Replace the
sensor.
Contact your
nearest DISCO
Service Office.
The sensor wiring is
broken.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm, then the ERROR RECOVERY (HANDLING)
screen is displayed.
(2) Close the inspection workpiece door.
(3) Select "CONTINUE AFTER REMOVING WORKPIECE" from the
recovery screen.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-47
E1033 : Water leakage detected. (θ-axis)
Error code
E1033
Message
Water leakage detected. (
θ-axis)
What was
detected
Water leakage was detected by the water leakage detector installed in the
θ-axis section.
During what
operation it
occurred
At any time.
State after
detection
The Z-axis retreats to the upper end and the spindle stops.
All axis drive systems come to an immediate stop, and then the machine
waits for system initialization.
Phenomenon Probable causes Remedy Reference
What to do
There is water
leakage at the
θ-axis section.
The waterproof cover
or O-ring is broken.
Replace the
waterproof cover
and O-ring of the
θ-axis section.
F-3-2
The error occurs
although no water
leaks.
The wiring of the
water leakage sensor
is broken.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm.
(2) Turn OFF the machine power.
(3)IfthewaterproofcoverorO-ringoftheθ-axis section is broken, replace
both with the new ones.
(4)Ifthereiswaterleakageattheθ-axis section, wipe off water.
(5) Wait more than one minute after turning OFF the machine power, and
then turn the power back ON.
(6) Effect system initialization.
(7) Turn on the wheel coolant water supply and check whether there is no
water leakage at the θ-axis section.
(8) Resume the operation.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-48
E1034 : Clean air pressure of S/T cleaning water dropped.
Error code
E1034
Optional accessory
Message
Clean air pressure of S/T cleaning water dropped.
What was
detected
In the machine incorporating the specification of the spinner atomizing
nozzle as an optional accessory, the clean airpressure declines to under the
lower limit set at [Atomizing clean air pressure] on the SENSOR
THRESHOLD DATA screen [screen 6.6].
During what
operation it
occurred
During spinner cleaning.
State after
detection
The cleaning operation will stop. The nozzle axis moves to its origin
position. The spinner table moves up.
Phenomenon Probable causes Remedy Reference
What to do
The error occurs
even when the
clean airpressure is
proper.
The wiring of the
pressure sensor is
broken.
Contact your
nearest DISCO
Service Office.
The sensor is
defective.
Replace the sensor.
The setting value of
the [Atomizing clean
air pressure] is too
high.
Correct the value.
Recovery
(1) Cancel the alarm.
(2) Press the <Sensor> button to call up the SENSOR STATUS screen.
(3) Make sure that the flow rate of "ATOMIZING CLEAN AIR
PRESSURE" on the <PRES> Page.
(4) Resume the cleaning operation.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
