D-47
E1033 : Water leakage detected. (θ-axis)
Error code
E1033
Message
Water leakage detected. (
θ-axis)
What was
detected
Water leakage was detected by the water leakage detector installed in the
θ-axis section.
During what
operation it
occurred
At any time.
State after
detection
The Z-axis retreats to the upper end and the spindle stops.
All axis drive systems come to an immediate stop, and then the machine
waits for system initialization.
Phenomenon Probable causes Remedy Reference
What to do
There is water
leakage at the
θ-axis section.
The waterproof cover
or O-ring is broken.
Replace the
waterproof cover
and O-ring of the
θ-axis section.
F-3-2
The error occurs
although no water
leaks.
The wiring of the
water leakage sensor
is broken.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm.
(2) Turn OFF the machine power.
(3)IfthewaterproofcoverorO-ringoftheθ-axis section is broken, replace
both with the new ones.
(4)Ifthereiswaterleakageattheθ-axis section, wipe off water.
(5) Wait more than one minute after turning OFF the machine power, and
then turn the power back ON.
(6) Effect system initialization.
(7) Turn on the wheel coolant water supply and check whether there is no
water leakage at the θ-axis section.
(8) Resume the operation.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-48
E1034 : Clean air pressure of S/T cleaning water dropped.
Error code
E1034
Optional accessory
Message
Clean air pressure of S/T cleaning water dropped.
What was
detected
In the machine incorporating the specification of the spinner atomizing
nozzle as an optional accessory, the clean airpressure declines to under the
lower limit set at [Atomizing clean air pressure] on the SENSOR
THRESHOLD DATA screen [screen 6.6].
During what
operation it
occurred
During spinner cleaning.
State after
detection
The cleaning operation will stop. The nozzle axis moves to its origin
position. The spinner table moves up.
Phenomenon Probable causes Remedy Reference
What to do
The error occurs
even when the
clean airpressure is
proper.
The wiring of the
pressure sensor is
broken.
Contact your
nearest DISCO
Service Office.
The sensor is
defective.
Replace the sensor.
The setting value of
the [Atomizing clean
air pressure] is too
high.
Correct the value.
Recovery
(1) Cancel the alarm.
(2) Press the <Sensor> button to call up the SENSOR STATUS screen.
(3) Make sure that the flow rate of "ATOMIZING CLEAN AIR
PRESSURE" on the <PRES> Page.
(4) Resume the cleaning operation.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-49
E1035 : Water flow of S/T cleaning water dropped.
Error code
E1035
Message
Water flow of S/T cleaning water dropped.
What was
detected
When the flow rate of spinner cleaning water is lower than the flow
rate sensor set value during spinner cleaning.
During what
operation it
occurred
During spinner cleaning.
State after
detection
The cleaning operation stops. The nozzle axis moves to its origin.
The spinner table moves upward.
Phenomenon Probable causes Remedy Reference
What to do
Flow rate is
normal but an
error occurs.
The flow rate sensor
wiring is broken.
Contact your
nearest DISCO
Service Office.
The flow rate sensor
is defective.
Replace the sensor.
The flow rate sensor
setting is too high.
Correct the sensor
setting.
Recovery
(1) Cancel the alarm, and then the ERROR RECOVERY (CLEANING)
screen is displayed.
(2) Perform the error recovery steps indicated on the screen.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
