D-67
B0593 : Z2-axis non-contact setup reappearance error.
Error code
B0593
Optional accessory
Message
Z2-axis non-contact setup reappearance error.
What was
detected
The difference between the first and second Z2-axis non-contact setups
exceeded the limit that had been defined in the SETUP DATA 1 screen
[screen 4.7].
During what
operation it
occurred
After Z2-axis setup operation.
State after
detection
The X- and Y-axes move to their origins and the alarm indication is given.
Setup data value registration does not take place.
Phenomenon Probable causes Remedy Reference
What to do
The error recurs
when setup is
attempted again.
The preselected limit
value is too small.
Check whether the
limit value setting
is 0.005 mm
(standard value).
Check whether the
non-contact setup
sensor is soiled.
Clean the non-
contact setup sensor
section and perform
sensor calibration
setup.
Erroneous detection
occurs during setup
operation due to
water drops on the
non-contact setup
sensor section.
Correct the setup
data value for the
setup blow time
setting.
Recovery
(1) Cancel the alarm.
(2) Select the setup operation again.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-68
B0594 : Z2-axis blade wear check error.
Error code
B0594
Message
Z2-axis blade wear check error.
What was
detected
The Z2-axis setup data for the blade wear check limit value was exceeded
by the difference between the current and previous setup values.
During what
operation it
occurred
After Z2-axis setup operation.
State after
detection
Setup data value registration does not take place.
Phenomenon Probable causes Remedy Reference
What to do
The error recurs
when setup is
attempted again.
Erroneous detection
occurs during setup
operation due to
water drops on the
setup position
section.
Increase the setup
data value for the
setup blow time
setting.
The non-contact
setup sensor is
soiled.
Clean the non-
contact setup
sensor.
The setup data value
for the Z2-axis blade
wear check limit
setting is too small.
Enter a limit setting
appropriate for the
Z2-axis blade wear
amount.
Recovery
(1) Cancel the alarm.
(2) Perform the customer-defined procedure for excessive blade wear.
(3) Perform the setup operation again.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-69
B0595 : Z2-axis setup data error.
Error code
B0595
Message
Z2-axis setup data error.
What was
detected
An attempt was made to initiate cutting with the Z2-axis although the Z2-
axis setup process was not completed.
During what
operation it
occurred
At the beginning of Z2-axis cutting.
State after
detection
No cutting operation can be initiated using the Z2-axis.
Phenomenon Probable causes Remedy Reference
What to do
Recovery
(1) Cancel the alarm.
(2) Cancel the cutting operation and perform the Z2-axis setup process.
(3) After the Z2-axis setup process is normally ended, resume the cutting
operation.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
