D-81
V0514 : Spinner table up error.
Error code
V0514
Message
Spinner table up error.
What was
detected
The up sensor input was not issued upon upward movement of the spinner
table.
During what
operation it
occurred
During spinner table up operation.
State after
detection
The spinner table moves down.
Transport stops.
Phenomenon Probable causes Remedy Reference
What to do
An error is issued
even though the
spinner table moves
upward.
The sensor position
is deviated.
Contact your
nearest DISCO
Service Office.
The sensor is
defective.
Replace the sensor.
The spinner table
does not ascend.
The spinner table up-
down air cylinder
piping is bent or
clogged.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm, and then the ERROR RECOVERY (HANDLING)
screen is displayed.
(2) Perform the error recovery steps indicated on the screen.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-82
V0515 : Spinner table down error.
Error code
V0515
Message
Spinner table down error.
What was
detected
The down sensor input was not issued upon downward movement of the
spinner table.
During what
operation it
occurred
During spinner table down operation.
State after
detection
The spinner table moves up.
Transport stops.
Phenomenon Probable causes Remedy Reference
What to do
An error is issued
even though the
spinner table moves
downward.
The sensor position
is deviated.
Contact your
nearest DISCO
Service Office.
The sensor is
defective.
Replace the sensor.
The spinner table
does not descend.
The spinner table up-
down air cylinder
piping is bent or
clogged.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm, and then the ERROR RECOVERY (HANDLING)
screen is displayed.
(2) Perform the error recovery steps indicated on the screen.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-83
V0517 : Spindle rpm error.
Error code
V0517
Message
Spindle rpm error.
What was
detected
It was found at the beginning of spindle rotation that the spindle rotation
speed was different from the setting.
During what
operation it
occurred
At the beginning of spindle rotation.
State after
detection
Neither the cutting operation nor the setup operation can be started.
Phenomenon Probable causes Remedy Reference
What to do
The error occurs
frequently.
The spindle inverter
voltage setting is
incorrect.
Contact your
nearest DISCO
Service Office.
The cable is broken. Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm.
(2) Select the operation again.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
