D-90
V1017 : Down error (Lower arm Lower cylinder).
Error code
V1017
Message
Down error (Lower arm Lower cylinder).
What was
detected
There is no input from Down-end sensor, when the lower arm lower
cylinder moves downward.
During what
operation it
occurred
Lower arm down operation.
State after
detection
Transport stops.
Phenomenon Probable causes Remedy Reference
What to do
The lower arm
lower cylinder
moves down, but an
error is issued.
The sensor position
is deviated.
Adjust the position
so that there is
sensor input when
the lower arm
lower cylinder is in
the down state.
The sensor is
defective.
Replace the sensor.
The lower arm
lower cylinder does
not perform the
down.
The lower cylinder
piping of the lower
arm section is bent or
clogged.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm, then the ERROR RECOVERY (HANDLING) screen
is displayed.
(2) Perform the error recovery steps indicated on the screen.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-91
V1018 : Upper Arm front end error.
Error code
V1018
Message
Upper Arm front end error.
What was
detected
There was no input on the front end sensor when the upper arm moves to
the front.
During what
operation it
occurred
When the upper arm moves to the front.
State after
detection
Transport stops.
Phenomenon Probable causes Remedy Reference
What to do
The error occurs
even though the
upper arm moves to
the front.
The sensor position
is deviated.
Adjust the position
so that there is
sensor input when
the upper arm is in
the front.
The sensor is
defective.
Replace the sensor.
The upper arm does
not move to the
front.
The air cylinder
piping of the upper
arm is bent or
clogged.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm, and then the ERROR RECOVERY (HANDLING)
screen is displayed.
(2) Perform the error recovery steps indicated on the screen.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-92
V1019 : Upper Arm rear end error.
Error code
V1019
Message
Upper Arm rear end error.
What was
detected
There was no input on the rear end sensor when the upper arm moves to the
rear.
During what
operation it
occurred
When the upper arm moves to the rear.
State after
detection
Transport stops.
Phenomenon Probable causes Remedy Reference
What to do
The error occurs
even though the
upper arm moves
the rear.
The sensor position
is deviated.
Adjust the position
so that there is
sensor input when
the upper arm is in
the rear.
The sensor is
defective.
Replace the sensor.
The upper arm does
not move to the
rear.
The air cylinder
piping of the upper
arm is bent or
clogged.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm, and then the ERROR RECOVERY (HANDLING)
screen is displayed.
(2) Perform the error recovery steps indicated on the screen.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
