D-113
A0538 : θ adjustment retry over.
Error code
A0538
Message
θ adjustment retry over.
What was
detected
The error was displayed when the θ alignment was not achieved although
realignment was attempted the number of times specified in the column
<RETRY COUNT> on theALIGNMENT DATA screen [screen 3.1.3].
During what
operation it
occurred
During auto alignment operation.
State after
detection
Auto alignment operation is temporarily halted.
Phenomenon Probable causes Remedy Reference
What to do
The error occurs
frequently.
The value specified
in the column <θ
ADJUST
PERMISSION> on
the ALIGNMENT
DATA screen [screen
3.1.3] is too small.
Correct the value
specified in the
column <θ
ADJUST
PERMISSION> on
the ALIGNMENT
DATA screen
[screen 3.1.3].
The value specified
in the column
[RETRY COUNT]
on the ALIGNMENT
DATA screen [screen
3.1.3] is too small.
Correct the value
specified in the
column [RETRY
COUNT] on the
ALIGNMENT
DATA screen
[screen 3.1.3].
Recovery
(1) Cancel the alarm, then the ERROR RECOVERY (ALIGNMENT)
screen is displayed.
(2) Perform the error recovery steps indicated on the screen.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-114
A0539 : This work has been cut.
Error code
A0539
Message
This work has been cut.
What was
detected
During street adjustment in auto alignment, cutting lines were found on a
street.
During what
operation it
occurred
During street adjustment in auto alignment.
This detection function is effective only when "FIRST" or "ALWAYS" is
set for the item [CUT WORK CHECK WHEN ALI.] in the USER DEFINE
DATA screen [screen 7.4].
State after
detection
Auto alignment operation is discontinued.
Phenomenon Probable causes Remedy Reference
What to do
The straight-line
pattern on the street
line is misrecognized
as a cutting line.
The amount and
position of light during
street adjustment is not
appropriate.
Conduct
teaching again.
Recovery
(1) Cancel the alarm, then the ERROR RECOVERY (ALIGNMENT)
screen is displayed.
(2) Perform the error recovery steps indicated on the screen.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-115
A0541 :ANGLE: Slice level error.
Error code
A0541
Optional accessory
Message
ANGLE: Slice level error.
What was
detected
Error display is made if a binary image cannot be recognized during angle
recognition execution.
During what
operation it
occurred
During angle recognition execution.
State after
detection
Angle recognition operation is discontinued.
Phenomenon Probable causes Remedy Reference
What to do
Binarization cannot
be done because the
recognition of the
light intensity is
inappropriate.
A black-white
decision cannot be
made because of lack
of contrast between
bright and dim parts.
Readjust the angle
recognition light
intensity of
alignment special
data.
Recovery
(1) Cancel the alarm, then the ERROR RECOVERY (ALIGNMENT)
screen is displayed.
(2) Perform the error recovery steps indicated on the screen.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
