A-25 Cassette stage (C ontinued) [Kinematic s pecification casse tte (only s upported by D FD6361)] On the casse tte stage, there a re the kinema pins which prevent the casse tte from moving off the setting position. ÿ K…
A-24
Cassette stage
[Standard specification cassette]
On the cassette stage, there are the cassette blocks which prevent the cassette
from moving off the setting position.
Each cassette block corresponds to different cassette type.
The illustration below shows the relationship between the cassette blocks and
cassette types.
2-6-1 cassette
2-8 cassette
2-6 cassette
2-5-1 cassette
Cassette stage top surface
2-8 cassette
300 mm 13slot standard cassette
[DFD6351] [DFD6361]
A-25
Cassette stage (Continued)
[Kinematic specification cassette (only supported by DFD6361)]
On the cassette stage, there are the kinema pins which prevent the cassette
from moving off the setting position.
ÿ
Kinema pin
A-26
Inspection section
The workpiece is carried to this section in order to be inspected.
ÿ
Inspection cover
(Inspection Workpiece Door)
FRONT
Inspection plate
