D-132 K0049 : Kerf cent er posi tion error. Error c ode K0049 Optional accessor y Message Kerf c enter posi tion erro r. W hat wa s detected The stree t ad justment pos ition is abnorm al in kerf center a lignm ent. Duri…
D-131
K0048 : Could not find kerf center.
Error code
K0048 Optional accessory
Message
Could not find kerf center.
What was
detected
This error occurs if the kerf center is not recognized in the kerf check
conducted with reference to the hairline center.
During what
operation it
occurred
During kerf check function execution.
State after
detection
The kerf check process stops.
The X-axis waits below the microscope (comes a temporary halt).
Phenomenon Probable causes Remedy Reference
What to do
The screen
indicates that the
kerf line is narrow.
The light intensity is
so low that the kerf
looks narrow.
Correct the kerf
line light intensity
setting.
Recovery
(1) Cancel the alarm, then the ERROR RECOVERY (KERF CHECK)
screen is displayed.
(2) Perform the error recovery steps indicated on the screen.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-132
K0049 : Kerf center position error.
Error code
K0049 Optional accessory
Message
Kerf center position error.
What was
detected
The street adjustment position is abnormal in kerf center alignment.
During what
operation it
occurred
During kerf center alignment.
State after
detection
The kerf center alignment will stop.
The X-axis waits under the microscope (comes a temporary halt).
Phenomenon Probable causes Remedy Reference
What to do
The target on the
screen is hard to
see.
It is possible that the
target is
misidentified due to
excess or deficiency
of light intensity.
Adjust the light
intensity.
Recovery
(1) Cancel the alarm, then the ERROR RECOVERY (ALIGNMENT)
screen is displayed.
(2) Perform the error recovery steps indicated on the screen.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-133
2-8. Axis-Related Error Remedies
Contents of axis-related error code
Error codes beginning with the character X represent axis-related error.
The second, third and fourth digits of the error code represent the axis name.
The fifth digit of an error code indicates the contents of the error.
Error code
indication
[1] X represents that the error is the axis-related one.
[2]
[1]
X
[3]
0
[2] The numbers represent the axis name.
005 X-axis related error
006 Y-axis related error
007 Z-axis related error
008 θ-axis related error
009 Unused
010 Spinner-axis related error
011 Nozzle-axis related error
012 Push-pull-axis related error
013 Elevator-axis related error
014 Frame centering-axis related error
015 Y2-axis related error
016 Z2-axis related error
[3] The numbers 0 to 9 represent the contents of the
error.
