D-141
X•••6: -axis vibration error (far).(…..Reinitialize.)
Error code
X•••6
Message
-axis vibration error (far).(…..Reinitialize.)
What was
detected
The axis vibration is large.
During what
operation it
occurred
At any time during axis operation.
State after
detection
Allaxescometoanimmediatestop.
Phenomenon Probable causes Remedy Reference
What to do
Loud sound comes
out during the
spindle axis
rotation (Y-axis).
The flange is
improperly balanced.
Contract your
nearest DISCO
Service Office.
The error occurs
frequently.
The maker data setup
for the axis
parameter data is
improper.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm.
(2) Effect system initialization.
(3) Set the operation prior to the error occurrence, and execute it again.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-142
X•••7: -axis position error.(…..Reinitialize.)
Error code
X•••7
Message
-axis position error.(…..Reinitialize.)
What was
detected
The number of pulses returning from the scale or encoder does not coincide
with the number of commands
During what
operation it
occurred
At any time during axis operation.
State after
detection
Allaxescometoanimmediatestop.
Phenomenon Probable causes Remedy Reference
What to do
The error occurs
frequently.
The drive axis is
overloaded.
Check for factors
which could
interfere axis
operation.
The axis operation
acceleration/decelera
tionrateistoohigh.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm.
(2) Effect system initialization.
(3) Set the operation prior to the error occurrence, and execute it again.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-143
X•••8: -axis scale retry error.(…..Reinitialize.)
Error code
X•••8
Message
-axis scale retry error.(…..Reinitialize.)
What was
detected
The error is displayed if the maximum permissible number of scale-based
correction retry operations was exceeded.
During what
operation it
occurred
At any time during axis operation.
State after
detection
Allaxescometoanimmediatestop.
Phenomenon Probable causes Remedy Reference
What to do
Loud sound comes
out during the
spindle axis
rotation (Y-axis).
The flange is
improperly balanced.
Contract your
nearest DISCO
Service Office.
The error occurs
frequently.
The maker data setup
for the axis
parameter data is
improper.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm.
(2) Effect system initialization.
(3) Set the operation prior to the error occurrence, and execute it again.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
