E-60 5-3. Greasing the Frame Centering A xis Operation flow The procedure for grea sing the frame centering axis consists of the following steps. 5-3-1 Preparation of greasin g the frame cent ering axis 5-3-2 Greasing th…

E-59

5-2-3. Completion of greasing the elevator axis

Procedures for completion of greasing the elevator axis

Step No. Do This

(Continued from the previous section)

Turn ON the facility power source.

Open the circuit breaker lever lockout and then turn ON the

circuit breaker.

Insert the key into the main switch and then turn ON the main

switch.

With the <CST UP> and <CST DOWN> buttons, shuttle the

elevator axis between the upper and lower end at least three times

to apply the grease uniformly to the entire axis.

E-60

5-3. Greasing the Frame Centering Axis

Operation flow

The procedure for greasing the frame centering axis consists of the following

steps.

5-3-1 Preparation of greasing the frame centering axis

5-3-2 Greasing the linear guide

5-3-3 Completion of greasing the frame centering axis

Safety items for greasing the frame centering axis

WARNING

If any touch panel control is inadvertently activated during

maintenance or inspection, unexpected machine operation may

cause death or serious injury.

While you don't use the touch panel, press the Disco's logo button

located at the upper left of the screen in order to lock up and

deactivate the touch panel.

CAUTION

When you perform maintenance with the outer cover removed,

observe the following precaution. If you stand the removed outer

cover against the machine, you may receive injury by the cover if it is

toppled by the earthquake or like that.

After taking off the outer cover for maintenance purposes, store it

sufficiently away from the working area.

NOTICE

Neither safety goggles, protective gloves, stepstools, flashlights nor

alcohol, all of which are necessary for maintenance work, are not

supplied with the machine. Use what are furnished in your factory or

what comply with your factory's standards.

E-61

Before greasing

Have on hand the following tools before starting greasing.

For the MSDS;

See the section G-2, [Material Safety Data Sheet (MSDS)].

Grease Name AFC grease

Maker THK

Part No. MOELJ007

Grease gun unit Name MG-70

Maker THK

Part No. MOELJ006

Lint-free waste

Spatula (resin)

Flashlight

Protective gloves

Phillips screwdriver
