F-28
1-4-4. Completion of replacing the spindle carbon brush
Summary of this section
This section describes the procedure to complete the replacement of the
spindle carbon brush.
1-4-4-1 Completion of replacing the spindle 1 carbon brush
- Procedure to complete the replacement of spindle 1 carbon
brush, that is followed when there is maintenance space
provided at the rear side of the machine
- Procedure to complete the replacement of spindle 1 carbon
brush, that is followed when there is no maintenance space
provided at the rear side of the machine
1-4-4-2 Completion of replacing the spindle 2 carbon brush
1-4-4-1. Completion of replacing the spindle 1 carbon brush
Procedures for completion of replacing the spindle 1 carbon brush
[When there is maintenance space provided at the rear side of the
machine]
Step No. Do This
(Continued from the previous section.)
1
Reinstall the partition that has been removed.
2
Reinstall cover [R] that has been removed.
[When there is no maintenance space provided at the rear side of the
machine]
Step No. Do This
(Continued from the previous section.)
1
Reinstall the bellows at the rear of the Y-axis.
- For the bellows installation procedures;
See the section 3-5 of this chapter, [Replacing the Bellows (for
Y-Axis)].
2
Reinstall the partition (left).
F-29
1-4-4-2. Completion of replacing the spindle 2 carbon brush
Procedures for completion of replacing the spindle 2 carbon brush
Step No. Do This
(Continued from the previous section.)
1
Reinstall the Y-axis section roll cover that has been removed.
2
Close the cover [P] and secure it with the retaining screws.
3
Reinstall the cover [A].
4
Open the facility main valve of air.
5
Turn ON the facility power source.
6
Open the lock of the circuit breaker lever and turn ON the circuit
breaker.
7
Insert the key into the main switch and turn ON the main switch.
F-30
1-5. Replacing the Spray Tip of the Spinner Section
Operation flow
The procedure for replacing the spray tip of the spinner section nozzle axis
consists of the following steps.
Note that the spinner atomizing nozzle [optional accessory] has no
consumable parts.
1-5-1 Preparation of replacing the spray tip
1-5-2 Replacing the spray tip
1-5-3 Completion of replacing the spray tip
Before replacement
Have on hand the following items for replacing.
- Wrench
