3-4-2. Replacing the O-ring
Procedures for replacing the O-ring
WARNING
- If you operate the machine while the machine interior or floor is wet
with water, you may receive electric shock that could result in
serious injury or death.
If the machine or floor is wet with water, do not turn ON the facility
power source until it dries.
- If any touch panel control is inadvertently activated during
maintenance or inspection, unexpected machine operation may
cause death or serious injury.
While you don't use the touch panel, press the Disco's logo button
located at the upper left of the screen in order to lock up and
deactivate the touch panel.
Step No. Do This
(Continued from the previous section)
1
Remove the O-ring.
O-ring
Table base
2
Replace the O-ring with a new one.
Model Part Name Part No.
DFD6351 O-ring MSCO0554AN
DFD6361 O-ring MSCO0565AN
3
Mount the spinner table on the table base.
- For the spinner table installation procedure;
See the section B-3-4, [Replacing the Spinner Table].
F-90
4. Consumables to Be Replaced at 1800-Day
(Recommended) Intervals
Summary of this section
This section describes consumables to be replaced at 1800-day intervals.
Section No. Title Contents
4-1 Replacing the Flowmeter - Procedures for replacing the
flowmeter
4-2 Replacing the Hard Disk
Drive
- Replacement of the hard disk
drive must be carried out by
Disco Service engineers.
F-91
4-1. Replacing the Flowmeter
Operation flow
The procedure for replacing the flowmeter consists of the following steps.
4-1-1 Removing the machine outer cover
4-1-2 Replacing the flowmeter
4-1-3 Completion of replacing the flowmeter
Before replacement
Have on hand the following items for replacing the flowmeter.
Phillips screwdriver
2.5mm Allen wrench
4mm Allen wrench
14mm wrench
17mm wrench
