All Bondhus

®

tools are made with Protanium

®

High Torque Steel.Made in the U.S.A.

ProGuard

™

ﬁ nish

delivers superior

corrosion protection

Inch

Sets

12145 HLX7 7 Long 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16” 1

12132 HLX8 8 Long .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32” 1

12138 HLX10 10 Long 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4” 1

12136 HLX12 12 Long .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16” 1

12137 HLX13 13 Long .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1

12243 HLX5S 5 Short .028, .035, .050, 1/16, 5/64” 1

12245 HLX7S 7 Short 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16” 1

12232 HLX8S 8 Short .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32” 1

12238 HLX10S 10 Short 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4” 1

12236 HLX12S 12 Short .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16” 1

12237 HLX13S 13 Short .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1

PART# MODEL# PCS LENGTH CONTENTS QTY LIST

For more individual sizes available packaged, in bulk, or singles see page 15

• Chamfered tool tips eliminate burrs and help tools

seat in screw head

• Sharp corners transfer more torque to the screw and

reduce stripping

• Precision machined for ease of use and superior ﬁ t

SIZE INCH MM INCH MM PART# QTY LIST EA

5/64 5.9 150 0.61 15 22704 5

3/32 5.9 150 0.65 16 22705 5

7/64 5.9 150 0.70 18 22706 5

1/8 5.9 149 0.75 19 22707 5

9/64 5.9 149 0.80 20 22708 5

5/32 5.8 148 0.84 21 22709 5

3/16 5.8 148 0.94 24 22710 5

7/32 5.8 147 1.03 26 22711 5

1/4 5.8 146 1.13 29 22712 5

5/16 5.7 144 1.25 32 22713 5

3/8 5.6 143 1.38 35 22714 5

5/64 11.9 303 0.61 15 25404 5

3/32 11.9 302 0.65 16 25405 5

7/64 11.9 302 0.70 18 25406 5

1/8 11.9 302 0.75 19 25407 5

9/64 11.9 301 0.80 20 25408 5

5/32 11.8 301 0.84 21 25409 5

3/16 11.8 300 0.94 24 25410 5

7/32 11.8 299 1.03 26 25411 5

1/4 11.8 298 1.13 29 25412 5

6”

LONG

ARM

Inch

12”

LONG

ARM

Inch

Singles Singles

Long

Short

L-Wrenches

- ProGuard

™

Finish -

Hex End L-Wrenches

PACKAGED

Yellow=Inch

Red=Metric

Inch

Sets

In Pouch

12335 PHLX9 9 Long 5/64, 3/32, 1/8, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1

12333 PHLX11 11 Long .050, 1/16, 5/64, 3/32, 1/8, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1

12351 PHLX15 15 Long 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8, 1/2 1

9/16, 5/8, 3/4”

12345 PHLX7S 7 Short 5/64, 3/32, 1/8, 5/32, 3/16, 7/32, 1/4” 1

12338 PHLX10S 10 Short .035, .050, 1/16, 5/64, 3/32, 1/8, 5/32, 3/16, 7/32, 1/4 “ 1

12341 PHLX11SS 11 Short .050, 1/16, 5/64, 3/32, 1/8, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1

12343 PHLX11S 11 Short 5/64, 3/32, 1/8, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8, 1/2, 9/16” 1

12347 PHLX15S 15 Short .028, .035, .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1

1/4, 5/16, 3/8”

22789 PHLX9-6 9 6” Long Arm 5/64, 3/32, 1/8, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8” 1

25445 PHLX7-12 7 12” Long Arm 5/64, 3/32, 1/8, 5/32, 3/16, 7/32, 1/4” 1

35393 HLX5SZ 5 Short .028, .035, .050, 1/16, 5/64”

(Bondhex™ case in ziplock bag)

1

PART# MODEL# PCS LENGTH CONTENTS QTY LIST

12347

Hex End Tips

Inch

Sets

In Metal Box

12344 MHLX15S 15 Short .028, .035, .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1

1/4, 5/16, 3/8”

12339 MHLX18S 18 Short .028, .035, .050, 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1

1/4, 5/16, 3/8, 1/2, 9/16, 5/8”

PART# MODEL# PCS LENGTH CONTENTS QTY LIST

12344

1234

4

Inch

Sets

In Plastic Box

12342 MHLX13 13 Long 1/16, 5/64, 3/32, 7/64, 1/8, 9/64, 5/32, 3/16, 7/32, 1/4, 5/16, 3/8, 1/2” 1

PART# MODEL# PCS LENGTH CONTENTS QTY LIST

12342

SINGLE PACKAGING SINGLE PACKAGING

35393

14

All Bondhus

®

tools are made with Protanium

®

High Torque Steel.

Made in the U.S.A.

ProGuard

™

ﬁ nish

delivers superior

corrosion protection

• Chamfered tool tips eliminate burrs and help tools

seat in screw head

• Sharp corners transfer more torque to the screw and

reduce stripping

• Precision machined for ease of use and superior ﬁ t

For sets and 6” and 12” Long Arm singles see page 14

SIZE INCH MM INCH MM

.028 2.6 66 0.22 6 12100 10 13900 100 15900 10

.035 2.7 68 0.34 9 12101 10 13901 100 15901 10

.050 2.8 72 0.53 13 12102 10 13902 100 15902 10

1/16 3.0 76 0.56 14 12103 10 13903 100 15903 10

5/64 3.2 81 0.61 15 12104 10 13904 100 15904 10

3/32 3.4 86 0.65 16 12105 10 13905 100 15905 10

7/64 3.6 90 0.70 18 12106 10 13906 100 15906 10

1/8 3.8 95 0.75 19 12107 10 13907 100 15907 10

9/64 4.0 101 0.80 20 12108 10 13908 100 15908 10

5/32 4.2 107 0.84 21 12109 10 13909 100 15909 10

3/16 4.5 114 0.94 24 12110 10 13910 100 15910 10

7/32 4.9 124 1.03 26 12111 5 13911 50 15911 5

1/4 5.3 133 1.13 29 12112 5 13912

50 15912 5

5/16 6.0 152 1.25 32 12113 5 13913 50 15913 5

3/8 6.8 171 1.38 35 12114 5 13914 50 15914 5

7/16 7.5 191 1.50 38 12115 1 13915 25 15915 1

1/2 7.8 198 1.63 41 12116 1 13916 25 15916 1

9/16 9.0 229 1.75 44 12117 1 13917 10 15917 1

5/8 9.8 248 1.88 48 12118 1 13918 10 15918 1

3/4 11.3 286 2.13 54 12119 1 13919 5 15919 1

7/8 12.7 322 2.37 60 12120 1 - - - -

1 14.1 359 2.62 67 12121 1 - - - -

1 1/4 17.0 432 3.00 76 12125 1 - - - -

1 1/2 20.3 514 3.50 89 12129 1 - - - -

PART# QTY LIST EA

Singles

SIZE INCH MM INCH MM

.028 1.2 31 0.22 6 12200 10 13800 100 15800 10

.035 1.2 31 0.34 9 12201 10 13801 100 15801 10

.050 1.6 42 0.53 13 12202 10 13802 100 15802 10

1/16 1.8 45 0.56 14 12203 10 13803 100 15803 10

5/64 1.9 48 0.61 15 12204 10 13804 100 15804 10

3/32 2.0 51 0.65 16 12205 10 13805 100 15805 10

7/64 2.1 54 0.70 18 12206 10 13806 100 15806 10

1/8 2.3 58 0.75 19 12207 10 13807 100 15807 10

9/64 2.4 61 0.80 20 12208 10 13808 100 15808 10

5/32 2.5 64 0.84 21 12209 10 13809 100 15809 10

3/16 2.8 70 0.94 24 12210 10 13810 100 15810 10

7/32 3.0 77 1.03 26 12211 5 13811 50 15811 5

1/4 3.3 83 1.13 29 12212 5 13812

50 15812 5

5/16 3.8 96 1.25 32 12213 5 13813 50 15813 5

3/8 4.3 108 1.38 35 12214 5 13814 50 15814 5

7/16 4.8 121 1.50 38 12215 1 13815 50 15815 1

1/2 5.3 133 1.63 41 12216 1 13816 50 15816 1

9/16 5.8 146 1.75 44 12217 1 13817 25 15817 1

5/8 6.3 159 1.88 48 12218 1 13818 20 15818 1

3/4 7.3 184 2.13 54 12219 1 13819 15 15819 1

7/8 8.2 207 2.37 60 12220 1 - - - -

1 9.2 232 2.62 67 12221 1 - - - -

1 1/4 11.0 279 3.00 76 12225 1 - - - -

1 1/2 13.0 330 3.50 89 12229 1 - - - -

1 3/4 13.3 337 4.00 102 12231 1 - - - -

2 15.0 381 4.50 114 12233 1 - - - -

PART# QTY LIST EA

LONG

Inch

SHORT

Inch

L-Wrenches

- ProGuard

™

Finish -

Hex End L-Wrench Singles

SINGLE PACKAGING

BULK

PACKAGED

TAGGED/BARCODED

Hex End Tips

15

All Bondhus

®

tools are made with Protanium

®

High Torque Steel.Made in the U.S.A.

Did y ou know...?

Bondhus tools are harder and

more ductile than competitors’

tools. They wear longer,

generate greater torque and

resist breakage and shattering.

Sets

Metric

ProGuard

™

ﬁ nish

delivers superior

corrosion protection

In Metal Box

In Pouch

12146 HLX6M 6 Long 1.5, 2, 2.5, 3, 4, 5mm 1

12192 HLX7M 7 Long 1.5, 2, 2.5, 3, 4, 5, 6mm 1

12199 HLX9M 9 Long 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1

12195 HLX15M 15 Long 1.27, 1.5, 2, 2.5, 3, 3.5, 4, 4.5, 5, 5.5, 6, 7, 8, 9, 10mm 1

12242 HLX5MS 5 Short .71, .89, 1.27, 1.5, 2mm 1

12246 HLX6MS 6 Short 1.5, 2, 2.5, 3, 4, 5mm 1

12292 HLX7MS 7 Short 1.5, 2, 2.5, 3, 4, 5, 6mm 1

12299 HLX9MS 9 Short 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1

PART# MODEL# PCS LENGTH CONTENTS QTY LIST

12396 MHLX10M 10 Long 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10, 12mm 1

12393 MHLX12MS 12 Short .71, .89, 1.27, 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1

12394 MHLX15MS 15 Short .71, .89, 1.27, 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10, 12, 14, 17mm 1

12349 PHLX15M 15 Long .89, 1.27, 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10, 12, 14, 17, 19mm 1

12392 PHLX7MS 7 Short 2, 2.5, 3, 4, 5, 6, 8mm 1

12399 PHLX9MS 9 Short 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10mm 1

12391 PHLX11MS 11 Short 2, 2.5, 3, 4, 5, 6, 7, 8, 9, 10, 12mm 1

12397 PHLX14MS 14 Short 2, 2.5, 3, 4, 5, 6, 7, 8, 9, 10, 12, 14, 17, 19mm 1

35392 HLX5MSZ 5 Short .71, .89, 1.27, 1.5, 2mm

(Bondhex™ case in ziplock bag)

1

For individual sizes available packaged, in bulk, or singles

see page 17

Long

Short

L-Wrenches

Metric

• Chamfered tool tips eliminate burrs and help tools

seat in screw head

• Sharp corners transfer more torque to the screw and

reduce stripping

• Precision machined for ease of use and superior ﬁ t

- ProGuard

™

Finish -

Hex End L-Wrenches

Yellow=Inch

Red=Metric

12394

12397

12

39

7

PART# MODEL# PCS LENGTH CONTENTS QTY LIST

Hex End Tips

Sets

1239

4
