Placement head CPP
Page 14 / 16 23.11.2021
Pos. Item no. Description Part marking
COMPL. / CPP
30 03063169-03 RETAINING PLATE COMPL. / CPP
31 03001830-01 CABLE SUPPORT SPARE PART
33 03082414-01 INSERT COMPL. - CE-TRANSLATOR /
CPP
34 03082418S01 COVER CPL. - CE TRANSDUCER /
CPP
SPARE PART
35 03036806S02 VAKUUM SENSOR COMPL. / CPP SPARE PART
36 03055431S01 GRINDING DISC / CPP SPARE PART
37 03054536-01 CLAMPING BRACKET / CPP
38 03078660-01 PLATE KD STATOR / CPP V2 SPARE PART
39 03068842-02 ENERGIE TRANSLATOR STATOR
COM. / CCP
SPARE PART
03080616-01 CABLE / CE TRANSDUCER / CPP SPARE PART
40 03064554-01 HOSE - HOLD CIRCUIT / CPP
00359176S01 PLASTIC HOSE,SILICON 1,5*3,5
ANTI-STATIC
SPARE PART
41 03049943S03 FILTER DISC CPL./CPP WEAR PART
03017818S01 O-RING 2X1.5 72NBR872 / C+P WEAR PART
42 03037106S04 COMPONENT SENSOR / CPP SPARE PART
43 03008362-02 BEARING SUPPORT/ C+P SPARE PART
44 03059398-01 FASTENING ELEMENT TC 102
45 03055438S01 PRESSURE CONTROL VALVE / CPP Spare Part
46 03054127-01 BACKGROUND_1 /CPP SPARE PART
47 03054211-01 BACKGROUND_2 /CPP SPARE PART
48 03054056-01 BACKGROUND_3 /CPP SPARE PART
49 03079153-02 BACKGROUND_4 / CPP SPARE PART
03063596S01 CABLE / HD - PRESSURE CONTROL
VALVE CPP
SPARE PART
50 03014437-01 CABLEHOLDER/ C+P SPARE PART
51 03065295S02 BOARD - ZV1 / CPP SPARE PART
52 03052586S03 BOARD - ZV2 / CPP SPARE PART
53 03041278-01 CABLE GUIDE / CPP
03063595S01 CABLE / COMPONENT-SENSOR / CPP SPARE PART
54 03073045-01 Z-ANGLE
55 03072245S01 RETAINIG PLATE FHE CCP
COMPLETE
SPARE PART
Placement head CPP
Page 15 / 16 23.11.2021
Pos. Item no. Description Part marking
56 03073355S03 BOARD KE-ACTIVATION ZV2 SPARE PART
03073187-01 FUSE ELEMENT / CPP SPARE PART
57 03070280-03 NOZZLE TYPE 2057 CPL. / TPU WEAR PART
59 03077294-01 TUBE / EXHAUST / CPP
60 03077296-01 TUBE / HOLDING CIRCLE / CPP
61 03077297-01 TUBE / PRESSURE CONTROL VALVE
/ CCP
62 03077299-01 TUBE / PULL-UP CYLINDER /CPP
63 03079493-01 SPIRAL HOSE / CPP
64 03085394S01 CO CAMERA C+P (TYPE 30) 27X27,
DIGITAL
SPARE PART
65 03018637S03 CO CAMERA C+P (TYPE 29) 27X27,
DIG. RK
SPARE PART
03079148-01 UPGRADE KIT CPP / X4I - A364
03077156-02 PIPING CPP / FHE X-SERIES SPARE PART
03077153-01 TUBE FHE / HEAD VALVE CPP X-
SERIES
03055411S01 PLASTIC TUBE PUN-CM-6-SW
ANTISTAT. (1M)
SPARE PART
03077154-01 TUBE FHE / HOLDING CIRCLE CPP X-
SERIES
03055411S01 PLASTIC TUBE PUN-CM-6-SW
ANTISTAT. (1M)
SPARE PART
00330249-01 BLANKING PLUG QSC-4H STANDARD PARTS
03006728S01 PVC CAP TYP D DI8,0 H 15 10X SPARE PART
03006777-01 COOLING AIR TUBE X-MOTOR
03006727S01 SILICON HOSE DI 8 DA 12
EL.CONDUCTIVE
SPARE PART
03074061S01 CABLE SET CPP / X-SERIE SPARE PART
77 03077980-01 PCB/ HEADBOARD CPP SPARE PART
03002397-03 CARD DC-DC CONVERTER, DP SPARE PART
00353445S04 SERVO AMPLIFIER SDS120/2,5S1 SPARE PART
03070900-01 AMPLIFIER SDS 120/1.5Z2 SPARE PART
81 03074861-01 NOZZLE STATION CPP CPLT. / X4I
00303593-01 DIN 84-M1,6 X 5-A2 STANDARD PARTS
00305383S01 PLUG-IN-SCREW-FITTING LCN-
M3-PK3
SPARE PART
00333782-01 DIN 7991-M4 X 20-8.8
Placement head CPP
Page 16 / 16 23.11.2021
Pos. Item no. Description Part marking
00316904-01 DIN 125-A 3,2-140HV-A2
00343075-01 DIN 9021 - 3,2 - 140 HV - A2
03051467-01 PIPING OF NOZZLE STATION / WITH
VALVE
SPARE PART
03055785-01 VALVE FOR NOZZLE STATION CPLT.
03056098-01 PUSH-IN THREADED L FITTING
QSML-M5-4
00047104-01 BLANKING PLUG B-M5 AL Spare Part
00330249-01 BLANKING PLUG QSC-4H STANDARD PARTS
03056097-01 PUN-CM 4X0.75 / 135MM
00359177S01 HOSE 4*2,5 PUN-CM-4 (PLACEMENT
HEAD)
SPARE PART
03056096-01 PUN-CM 4X0.75 / 200MM
00359177S01 HOSE 4*2,5 PUN-CM-4 (PLACEMENT
HEAD)
SPARE PART
97 03048638-02 BOX SPARE PART
03082143-01 SCREW SET CAMERA / HOLDING
SHEET
Spare Part
