1 Introduction 1.4 Important notes on this instruction manual 14 Instruction manual ASM ProcessLens 03/2021
1 Introduction
1.4 Important notes on this instruction manual
Instruction manual ASM ProcessLens 03/2021 13
1.4.5.2 ASM on the World Wide Web (WWW)
Log in to our ASM® homepage at www.asm-smt.com.
You can choose between the German and English version.
The different sections contain information about our products, services and contact persons.
In addition, registered customers can also access the MySIPLACE user group. Here you can call
up special information about our placement systems, e.g.
●
Technical documentation
●
Technical information
●
Spare parts lists
Registration for the MySIPLACE user group is very simple:
► Click on MyASM and then on Registration.
► Fill in the registration form and send it off to us.
Soon afterwards, you will receive your access authorization with user name and password.
1.4.6 Abbreviations
CEE Commission on the Rules for the Approval of the Electrical Equipment
DLP Digital Light Projector
EMC Electromagnetic compatibility
EMF Electric and Magnetic Fields
ESD Electrostatic sensitive device
GND Ground
MOS Metal-Oxide-Semiconductor
PCB Printed circuit board
SC Station computer
SMD Surface mounted device
1 Introduction
1.4 Important notes on this instruction manual
14 Instruction manual ASM ProcessLens 03/2021
2 Safety
2.1 Conventions for the use of safety instructions and symbols
Instruction manual ASM ProcessLens 03/2021 15
2 Safety
DANGER
Non observance of the following safety instructions may cause injury to personnel
and damage to the machine!
► Please observe the safety instructions in this Instruction Manual!
2.1 Conventions for the use of safety instructions and
symbols
Safety instructions
This manual contains notes that must be observed to guarantee your personal safety and to avoid
damage to equipment. These notes are highlighted by warning triangles and are indicated as fol-
lows according to the level of risk:
DANGER
Definition
For the purposes of this manual, this indicates that fatal or severe injuries or considerable
damage to property will occur if this hazard warning is not observed.
WARNING
Definition
For the purposes of this manual, this indicates that fatal or severe injuries or considerable
damage to equipment may occur if these warning instructions are not followed.
CAUTION
Definition
For the purposes of this manual, this indicates that minor injuries or damage to property
may occur if this caution is not observed.
NOTICE
Definition
For the purposes of this manual, this note provides information about the product or indic-
ates a part of the manual that requires particular attention.
Symbols
Example Description
Next This typeface marks controls and interface elements in the software.
► This symbol indicates actions that have to be performed by the operator.
2.1.1 Qualified personnel
Qualified or adequately trained personnel means that these people are familiar with the setting up,
operation and preventive maintenance of ASM ProcessLens solder paste inspection machine and
add-on devices and are suitably qualified, e.g.
●
Have been trained, instructed or authorized to switch on and off, isolate, earth and identify
electrical circuits and system components in accordance with normal safety standards.
●
Have been trained or instructed in the upkeep and use of appropriate safety equipment in
accordance with normal safety standards.
