2 Safety 2.2 Warning labels Instruction manual ASM ProcessLens 03/2021 21 Fig.6: Warning labels back view 1 W 203 [03009342-xx] 2 W 210 [03009350-xx] only available at the ASM ProcessLens Dual-lane
2 Safety
2.2 Warning labels
20 Instruction manual ASM ProcessLens 03/2021
2.2.1 Warning labels on the machine
Fig.5: Warning labels front view
1 W 201 [03009338-xx] 2 W 202 [03009341-xx]
3 External grounding point [00359574-xx] 4 W 204 [03009343-xx]
5 W laser class 2 [03134118-xx] 6 W 81-00382 [03112319-xx]
7 W 203 [03009342-xx] 8 W 210 [03009350-xx]
2 Safety
2.2 Warning labels
Instruction manual ASM ProcessLens 03/2021 21
Fig.6: Warning labels back view
1 W 203 [03009342-xx] 2 W 210 [03009350-xx] only available at
the ASM ProcessLens Dual-lane
2 Safety
2.2 Warning labels
22 Instruction manual ASM ProcessLens 03/2021
2.2.2 Warning labels in the machine
Fig.7: Warning labels - front view - inside - part 1
1 W 202 [03149289-xx] 2 W 204 [03009343-xx]
3 Do not touch
