1 Introduction
1.1 Machine overview
Instruction manual ASM ProcessLens 03/2021 7
1 Introduction
This instruction manual contains basic information that must be observed when setting up, operat-
ing and maintaining the ASM ProcessLens® solder paste inspection machine (Single-lane and
Dual-lane). This instruction manual contains notes that must be observed to guarantee your per-
sonal safety and to avoid damage to equipment.
NOTICE
The ASM ProcessLens® solder paste inspection machines are of largely identical design.
Any differences will be mentioned specifically.
The diagrams in this instruction manual show the ASM ProcessLens Dual-lane. These dia-
grams also apply in principle to the ASM ProcessLens Single-lane. Additional diagrams will
be shown for any deviations.
This document is the original instruction manual.
1.1 Machine overview
Fig.1: ASM ProcessLens solder paste inspection machine
