4 Setting up and commissioning 4.4 Commissioning the machine Instruction manual ASM ProcessLens 03/2021 73 Fig.48: Position of the shipping braces - Front side of the machine (part 3) 1 Shipping braces
4 Setting up and commissioning
4.4 Commissioning the machine
72 Instruction manual ASM ProcessLens 03/2021
Fig.47: Position of the shipping braces - Front side of the machine (part 2)
1 Shipping braces
4 Setting up and commissioning
4.4 Commissioning the machine
Instruction manual ASM ProcessLens 03/2021 73
Fig.48: Position of the shipping braces - Front side of the machine (part 3)
1 Shipping braces
4 Setting up and commissioning
4.4 Commissioning the machine
74 Instruction manual ASM ProcessLens 03/2021
Fig.49: Position of the shipping brace - Rear side of the machine
1 Shipping brace
