6 Preventive Maintenance
6.1 Safety instructions
82 Instruction manual ASM ProcessLens 03/2021
6.1 Safety instructions
WARNING
Risk of burns
► When performing cleaning tasks using flammable fluids (e.g. alcohol), never use a
naked flame or open light sources.
► Never spray lubricants or cleaning agents in spray cans in the vicinity of open light
sources or naked flames.
► Never spray lubricants anywhere near the optical head as major damage can occur to
the measurement system.
WARNING
SIPLACE cleansing tissue
The SIPLACE cleansing tissue is harmful to your health if swallowed and could cause dam-
age to your lungs.
► Do not breathe in the aerosol/mist.
► Avoid contact with the skin. If swallowed, do not induce vomiting. Seek medical advice
immediately and show the packaging or label to the doctor.
► Wear latex gloves when using the cleansing tissue.
CAUTION
Non observance of the safety instructions poses a risk of personal injury and dam-
age to the machine!
► Observe the safety instructions in chapter Safetyof this Instruction Manual when per-
forming any work.
CAUTION
Consumables
► Observe the safety datasheets for the consumables!
CAUTION
Cleaning and lubrication
► Do not use any solvents for cleaning, use only ethanol!
► Alternatively, you can also use isopropanol – IPA.
► It is prohibited to clean with compressed air inside the machine or module assemblies.
CAUTION
Only one person is permitted to be present at any one time for each component sup-
ply place.
The reason for this is to ensure the safety of the operating personnel or of a second person.
The two-hand operation of the component trolley insert only enables one person to be reli-
ably protected from danger.
6.1.1 Safety instructions for hazardous substances
CAUTION
Observe the safety data sheets
► When handling hazardous substances, (e.g. Loctite 241, ethanol) observe the applic-
able safety data sheet.
6 Preventive Maintenance
6.2 Maintenance tasks overview
Instruction manual ASM ProcessLens 03/2021 83
6.2 Maintenance tasks overview
Maintenance Task Workflow Workflow 1 Workflow 2 Workflow 3 Workflow 4
Maintenance Tasks (Weekly)
Check & Clean Fans on Machine X X X X
Check/clean magnetic surfaces on the X
and Y axes
X X X X
Vacuum conveyor X X X X
Maintenance Tasks (3-monthly)
Clean Y1 Gantry Roller Plate X
Replace lubrication system Y-Axis X
Maintenance tasks (6-monthly)
Clean and preserve the hexagonal shafts X
Clean and preserve the Conveyor recir-
culating ball screws
X
Cleaning and Preserving the Conveyor
Guide Shafts
X
Cleaning and Preserving the Conveyor
Linear Guide
X
Maintenance tasks (12-monthly)
2D/3D Calibration X
Check the safety features X
Clean the protective covers X
Check/clean/replace the gas pressure
springs on the protective covers
X
Clean the X axis linear guides X
Clean the Y axis linear guides X
Grease the X axis guide bearing X
Grease the Y axis guide bearing X
Height Target Verification (Golden Unit) X
