Cable trees Page 64 / 87 24.11.2021 Pos. Item no. Description Part marking 00372913-01 CABLE EXTENSION STEPPING MOTOR 00369020-01 CABLE LIFTING TABLE PLACEM. AREA 1 TR. 1 00369071-01 CABLE LIFTING TABLE PLACEM.AREA 2 TR.…
Cable trees
Page 63 / 87 24.11.2021
Pos. Item no. Description Part marking
03080616-01 CABLE / CE TRANSDUCER / CPP SPARE PART
03063596S01 CABLE / HD - PRESSURE CONTROL
VALVE CPP
SPARE PART
03063595S01 CABLE / COMPONENT-SENSOR / CPP SPARE PART
159 03032879-02 CYLINDER SENSOR - CABLE ASSY,
COMPLETE
SPARE PART
00372913-01 CABLE EXTENSION STEPPING
MOTOR
00369020-01 CABLE LIFTING TABLE PLACEM.
AREA 1 TR. 1
00369071-01 CABLE LIFTING TABLE
PLACEM.AREA 2 TR. 1
00369073-01 CABLE LIFTING TABLE PLACEM.
AREA 1 TR. 2
SPARE PART
00369074-01 CABLE LIFTING TABLE PLACEM.
AREA 2 TR. 2
00365723-01 CABLE PCB CONVEYOR SIDE PANEL
A
00365724-01 CABLE PCB CONVEYOR SIDE PANEL
B
00365725-01 CABLE PCB CONVEYOR SIDE PANEL
C
00365726-01 CABLE PCB CONVEYOR SIDE PANEL
D
00365546-02 ADAPTER CABLE POWER SUPPLY
00369003-01 CABLE SMEMA INTERFACE TRACK 1
UPSTR. ST.
00369004-01 CABLE SMEMA INTERF. TRACK 1
DOWNSTR. ST.
00369005-02 ADAPTER CABLE SMEMA INTERFACE
TRACK 2V
00369006-02 ADAPTER CABLE SMEMA INTERFACE
TRACK 2N
00369054-04 GROUNDING WIRE HOUSING
00369053-04 GROUNDING WIRE CONVEYOR
CONTROL
00372329-01 CABLE: DISTRIBUTOR PCB
BARCODE READER
SPARE PART
31 03039849-01 GROUND WIRE 2.5QMM 570MM
159 03032879-02 CYLINDER SENSOR - CABLE ASSY,
COMPLETE
SPARE PART
Cable trees
Page 64 / 87 24.11.2021
Pos. Item no. Description Part marking
00372913-01 CABLE EXTENSION STEPPING
MOTOR
00369020-01 CABLE LIFTING TABLE PLACEM.
AREA 1 TR. 1
00369071-01 CABLE LIFTING TABLE
PLACEM.AREA 2 TR. 1
00365723-01 CABLE PCB CONVEYOR SIDE PANEL
A
00365724-01 CABLE PCB CONVEYOR SIDE PANEL
B
00365546-02 ADAPTER CABLE POWER SUPPLY
00369003-01 CABLE SMEMA INTERFACE TRACK 1
UPSTR. ST.
00369004-01 CABLE SMEMA INTERF. TRACK 1
DOWNSTR. ST.
00369054-04 GROUNDING WIRE HOUSING
00369053-04 GROUNDING WIRE CONVEYOR
CONTROL
00372329-01 CABLE: DISTRIBUTOR PCB
BARCODE READER
SPARE PART
03051896-01 CABLE: EXT. FAN HOOD 1-PIECE
03052316-02 CABLE: FANS HOOD 1-PIECE
03057223-01 CABLE: SUB DISTRIBUTOR - FANS
03056891-01 CABLE: DC/DC CONVERTER - RELAY
03057045-01 CABLE: EXTENSION DC-DC-
CONVERTER
03056890-01 CABLE: SUB DISTRIBUTOR - RELAY
03055171-01 CABLE: EXTENSION HOOD FANS
03002495-03 CABLE: FRAME PE
00335210-02 CABLE: MAIN SUPPLY MACHINE SPARE PART
03050908-01 CABLE: POWER SUPPLY BOX PC
03052633-01 CABLE: POWER SUPPLY USB-HUB
VIDEOMULTIPLEXER
03051747-01 CABLE: COMPUTER 1 - VIDEO
MULTIPLEXER
03051748-01 CABLE: MACHINE CONTROLLER -
VIDEO MULTIPLEXER
03051755-01 CABLE: CONTROL COMPUTER USB-
HUB
03051756-01 CABLE: LAN CONTROL COMPUTER
Cable trees
Page 65 / 87 24.11.2021
Pos. Item no. Description Part marking
MACHINE CONTROLLER
03042074-02 CABLE: HOTLINK INTERFACE
POWER
SPARE PART
03042074-02 CABLE: HOTLINK INTERFACE
POWER
SPARE PART
03072177-01 CABLE: POWER BOXPC AND VIDEO
MULTIPLEXER
03051747-01 CABLE: COMPUTER 1 - VIDEO
MULTIPLEXER
03021166-01 CABLE: ADAPTER BOARD, C+P20 SPARE PART
22 00332896-01 CABLE: CONTROL UNIT -CUTTER
LEFT VALVE
SPARE PART
23 00334380-01 CABLE: CONTROL UNIT-CUTTER
RIGHT VALVE
SPARE PART
03053222-01 CABLE DOCKING UNIT X-SERIES:
CAN BUS
03053223-01 CABLE DOCK.UNIT X-SERIES:
NOZZLE STATION
03053224-01 CABLE DOCKING UNIT X-SERIES:
FCU SIGNAL.
03053225-01 CABLE DOCKING UNIT X-SERIES: NC-
CAN-NODE
SPARE PART
03053226-01 CABLE DOCK. UNIT X-SERIES:FCU
DOCK.UNIT
03053227-01 CABLE DOCKING UNIT X-
SERIES:VALVE ON/OFF
03053228-01 CABLE DOCKING UNIT X-SERIES:
SAFETY
03053229-01 CABLE DOCK.UNIT X-SERIES: COMP.
REJ. BOX
03021042-01 CABLE X-SERIES HF R2 / ADAPTER
CONNECTOR
03051652-01 CABLE, X-S/POWER/ DATA,EDIF
UNLOCK. RAIL
SPARE PART
03063590-01 CABLE: TAPE CUTTER X-SERIES SPARE PART
03063599-01 CABLE COT X-SERIES: POWER
03063601-01 CABLE COT-INSERT X-SERIES:
REJECT BOX
03063604-01 CABLE COT-INSERT X-S: COT-
INSERT CONTROL
03063605-01 CABLE COT-INSERT X-SERIES: FCU
SIGNALING
