Preface
i
Preface
Thank you for purchasing Samsung Techwin’s SMN-Tape Feeder. (hereinafter referred to
as “SM Feeder”).
This device is a tape feeder exclusively used for the SM-series machines. A feeder is a
device that supplies parts to be mounted on a PCB.
Since this feeder contains a device driven by pneumatic pressure as well as a power unit
to which power is supplied, improper operation may cause injury to the user.
The “user” mentioned here includes any individual who performs operation and
maintenance.
Before operating
Before using SM-Feeder, please read this manual and understand its contents. Please
keep this manual near the machine at all times so that it can be referred to as
necessary.
A user who has not received training for the SM feeder may get injured due to
incorrect operation.
Samsung Techwin also provides a training program for operating this machine. For
details, please contact the local agent designated by Samsung Techwin Co., Ltd.
To assure safety in the operation and maintenance of the machine, it is very important
for the user to know the location of potential safety hazard.
Never attempt to modify the equipment without prior consent of Samsung Techwin
Co., Ltd. or repairs it in a manner not stated in this manual.
Samsung Techwin Co., Ltd.
(http://www.samsung-smt.com
)
Customer Complaint Center
Tel: +82-31-740-8285
Fax: +82-31-732-0606
E-mail: smtcs@samsung.com
STS Co., Ltd.
The representative C/S Company
4F, Korea Tsukiji B/D, 135-2, sangdaewon 1-dong, jungwon-gu, seongnam-si,
gyeonggi-do, Republic of Korea (Post Code: 462-807)
Tel: +82-31-743-6500, 6732~4
Fax: +82-31-743-6784
Samsung SM-Series Pneumatic Tape Feeder Users' Manual
ii
About Safety
In order to prevent damage to the property and to ensure safety, comply with the “must-
observe” items marked as follows.
Cautions to be exercised for the safety are described as follows in this manual.
Danger
If the instructions following this symbol are not
followed, serious accidents could occur, or death or
serious injury of the operator could happen. Be sure
to follow the instructions.
Warning
If the instructions following this symbol are not
followed, serious accidents could occur, or serious
injury of the operator could happen. Be sure to follow
the instructions.
Caution
If the instructions following this symbol are not
followed, damage of machine hardware, software, and
data could occur or the operator could be injured. Be
sure to follow the instructions.
The basic points to be observed while in using SM-Feeder are as follows.
Warning
Repair and adjustment of the tape feeder must be
performed by our C/S personnel or personnel in
charge who have received related training.
Do not perform work that may damage the power
source and associated pneumatic system devices.
Do not perform operation while hands are wet or
unclean.
Caution
Perform periodic inspection and maintenance of the
tape feeder.
Take care to ensure that the feeder does not receive
damage due to drop, impact, etc. during transportation
or installation.
Preface
iii
Concerning storage
Basic items to be observed with regard to the storage of the SM feeder are as follows.
Cautions against tape feeder storage and tape feeder reel replacement
Storing or replacing the reel while tape feeders are stacked may cause damage or
deformation to the components of the tape feeder. When replacing the tape feeder reel,
use the tape feeder replacement rack. Store the tape feeders on a stacking rack.
Do not store the feeders in places where temperature and humidity level are high
Avoid storing feeders in locations with high humidity or where the temperature is
higher than 40ºC. Rust or dewing may have negative effects on the driving part and
electronic circuit.
Do not store feeders in a location where magnetism is generated
If feeders are stored in a location where magnetism is generated, ensure that the area
from which the components on the reel are picked up is not magnetized.
Magnetization of such area may lead to problems with the smooth supply of
components.
Do not pile feeders up on one another
Place of high temperature and high humidity
