Specifications
XL Preheater Set
PHXLE-1K A 120V. Input 120/208V. 50/60Hz. Fuse T20A
PHXLE-2KA 230V. Input 230/400V. 50/60Hz. Fuse T10A
PHXLE-9KA 100V. Input 100/200V. 50/60Hz. Fuse T20A
XL Preheater Unit
- Maximum Power: 5400W
- Heating Area (L x W): Zone A 510 x 200 mm / 20 x 7.9 in
Zone B 510 x 410 mm / 20 x 16.1 in
Zone A+B 510 x 610 mm / 20 x 24 in
- Ambient Operating Temperature: 10 - 50 ºC / 50 - 122 ºF
- Temperature Range: 50 - 250 °C / 120 - 482 ºF
- Temperature Measurement: Thermocouple type K
- JBCset Temperature Profiles: 3 profiles (2, 3 or 4 steps)
- User Profiles: 22 (up to 6 steps for each)
- Maximum Work Time: 600 min or indefinite
- Dimensions / Weight: 790 x 664 x 42 mm / 18 kg
(L x W x H) 31.1 x 26.1 x 1.65 in / 39.7 lb
XL PCB Support (PHXL-SA)
- Weight: 4.1 kg / 9 lb
- Dimensions (Low Position): 752.5 x 737 x 78 mm
(L x W x H) 29.6 x 29 x 3.1 in
- Dimensions (High Position): 752.5 x 737 x 98 mm
(L x W x H) 29.6 x 29 x 3.9 in
XL Preheater Set
- Total Net Weight: 23 kg / 50.7 lb
- Total Package Dimensions / Weight: 1200 x 800 x 374 / 68.5 kg
(L x W x H) 47.2 x 31.5 x 14.7 in / 151 lb
Complies with CE standards.
ESD protected.
www.jbctools.com
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
Get 1 extra year JBC warranty by registering here:
https://www.jbctools.com/productregistration/
within 30 days of purchase.
