759 1925 684 393 527 1550 557 2131 1645 900 789 168 680 439 PL Front Rail Fixed Position FL 522 1550 Keyboard stroke 1 04 Keyboard height 870 Mo nitor s tro ke 165 Monitor center1349 Dimensions VT - X7 50 Specifications H…
2
times
Inspection speed
VT-X700
70.9 seconds
Inspection speed
VT-X750
34.8
seconds *
or more
* Exclude load and unload
Components
BGA
×
2
LGA
×
2
QFP
×
4
Connector
×
2
Chip, etc.
×
1,500
I
ns
pec
tion s
pee
d
2
,
5
00
160
mm
Void
Non-wet
d
n
-we
t
BGA, 3D rendering image
+
Productivity
Security
Capability
Safety
160
160
mm
mm
240
mm
Best Quality at the Minimum Q-cost.
VT-X750
The VT-X750 improves upon previous Omron 3D-CT technology making it the fastest X-Ray inspection system to date *¹.
The automated inspection logic has been improved for many parts such as IC heal fillets, stacked devices (PoP), through hole
components, press-fit connectors, and other bottom terminated parts.
Increasing automated inspection speed and expanding inspection logic enables full, in-line inspection coverage by 3D-CT
method.
*1. By an internal investigation in October, 2017.
Productivity
In-line full inspection coverage
OMRON’s unique 3D-CT reconstruction algorithms provide excellent solder shape recognition
and defect detection.
Quantitative analysis allows for an automated inspection process which minimizes the risk of
escapes while providing fast and repeatable operation.
Capability
Dense and dual sided board
design can provide challenges
for X-Ray inspection.
However, Omron's 3D-CT tech-
nology can overcome such
design restraints.
Design
constraint free
Visualize solder joint strength
8 FOV’s
Visualize
solder joint
strength
Innovation to maximize ROI.
Production line
Cloud
Remote access
via mobile
communication
network
Monitoring
Machine
record
Maintenance
Main
tena
nce
Remote
support
Trouble shooting
Trouble
shooting
Root cause
analysis
Remote Support
Monitor the machine's status and eliminate production down time.
Global Support
More than 30 locations.
Industrial
open network
Machine control
open network
Europe
UK
Germany
France
Hungary
Spain
Romania
Italy
Portugal
Netherlands
Russia
Asia Pacific
Singapore
Thailand
Malaysia
Indonesia
India
Philippines
Vietnam
South
America
Brazil
Argentina
North and
Central
America
US
Canada
Mexico
Japan (HQ)
Korea
China
China
Taiwan
Visualize the SMT line process quality by linking production
equipment status to inspection results.
IoT Solution on SMT
Status observation and analysis
Link
Quality data
Production data
Visualize
the process quality
Warning detection
Analyze defect trends
throughout the
production process.
Monitor process
variations and
visualize result data.
AXIAOIAOISPIPrinter Pick and place Reflow oven
Achieve zero-defect SMT line using Q-up Auto
A
Security
Safety
Operation safety
To achieve “Zero down time” during the SMT production process, OMRON supports machine operation globally by preventative
maintenance, emergency support and machine monitor with remote access.
r High speed imaging technology
The VT-X750 provides the shortest X-ray exposure time without
sacrificing inspection image quality.
r X-ray source at the bottom
By locating the X-ray source under the board, both exposure
and dosage is physically reduced to the more important
devices mounted on the top.
r Low energy-cut filter
Standard equipped filter reduces X-ray exposure further
minimizing damage concerns to memory products.
r Ultratrace leakage dose
Exposure dosage to operator is less than 0.18 mSv *² per a year. This is less
than one-tenth compared with that from natural environment.
r OMRON’s safety components
The VT-X750 complies with CE, SEMI S2/S8 and
other safety standards by utilizing OMRON’s latest
generation of safety controller and light curtain
products.
r9SBZTIJFMEJOHCPYNBEFJO+BQBO
The machine shielding quality is ensured through
three surveys (twice at the factory in Japan and once on site).
Zero down time
Reduce radiation exposure
*2. Teaching operation for one hour per day.0.5μSv/h x 1h/day x 365days = 0.183mSv
S
+
7591925684
393
5271550557
2131
1645
900
789 168
680 439
PL
Front Rail Fixed
Position
FL
522
1550
Keyboard stroke 104
Keyboard height 870
Monitor stroke 165
Monitor center1349
Dimensions
VT-X750
Specifications
Hardware configuration /
Function
Item
Description
Model
Inspection object
Inspection items
VT-X750
BGA/CSP, inserted components, SOP, QFP, transistors, R/C chips, bottom-side terminal components, QFN, Power devices
Open, non-wet, solder amount, shifting, foreign object, bridging, lead presence, etc. (selectable to applications)
3D-slice imaging by using parallel CT
6, 8, 10, 15, 20, 25 or 30 μm/pixel (selectable in the inspection program)
Micro-focus closed tube (130 kV)
Flat panel detector
50 x 50 to 610 x 515 mm (2 x 2 to 24 x 20 inch) , Thickness: 0.4 to 5.0 mm
Less than 4.0 kg (with component mounted)
Top: Less than 50 mm, Bottom: Less than 40 mm
Less than 2.0 mm
1,550(W) x 1,925(D) x 1,645(H) mm
Approx. 2,970 kg
900 ±15 mm
Single phase, 200 to 240 VAC, 50/60 Hz
2.4 kVA
Less than 0.5 μSv/h
0.4 to 0.6 Mpa
CE, SEMI, NFPA, FDA
Method
Resolution
X-ray source
X-ray detector
Size
Weight
Component clearance
Warpage
Footprint
Weight
Conveyor height
Power supply
Rated power
X-ray leakage
Air supply
Safety standard
Imaging
system
PCBA
Main body
EtherNet / IP™ is the trademark of ODVA.
EtherCAT
®
is registered trademark and patented technology, licensed by Beckhoff Automation GmbH, Germany.
[ Unit : mm
]
VT-X700
VT-X750
VT-X700
VT-X750
2,180
mm
1,550
mm
1,925
mm
2,500
mm
1,720
mm
1,645
mm
45
%
Footprint
5.45 m²
2.99 m²
V
VT
X
70
0
VT
VT
VT
-X
X
70
70
0
0
T
T
T
T
T
T
T
-
T
T
-
X
X
X750
-X
75
0
-
T
T
VT
VT
0
0
T
T
-
T
T
-
VT
X
V
V
VT-
X75
0
0
0
mm
0
mm
25
1,925
mm
m
250
2,50
0
0
mm
5
.45
m
²
299
2.99
m
m
²
²
VT-X700
VT-X750
reduced
630
mm
In-line length
shorter
Cat. No. Q331-E1-01
