3 Installing SIPLACE Explorer Installation and Configuration Guide SIPLACE Explorer
3.1 Initial Installation of SIPLACE Explorer 2.0 SP1 Edition 12/2005 EN
26
Hardware Requirements SIPLACE Line Server:
– all requirements of the existing SIPLACE Line Server
– 2 GB memory
– 10 GB available hard drive capacity
3
Software Requirements Central Database/Web Server:
– System environment - one of the following versions:
– Windows 2000 Server with SP4
– Windows 2003 Server with SP1
– MS SQL-Server (not MSDE) for the computer which is used as central database server
– Explorer installation:
– Tomcat Webserver
–JAVA 2 JRE
– Factory Configuration
Hardware Requirements Central Database/Web Server:
– all requirements of the existing SIPLACE Line Server
– Computer with 2.4 GHZ CPU
– 2 GB memory
– 30 GB available hard drive capacity
NOTE
Please note that the SIPLACE Explorer host computer can only be used for one application in this
installation variant. 3
Installation and Configuration Guide SIPLACE Explorer 3 Installing SIPLACE Explorer
Edition 12/2005 EN 3.1 Initial Installation of SIPLACE Explorer 2.0 SP1
27
3
Fig. 3 - 2 Installation variants: Line
only for 1 application
per line
SIPLACE Line Server
(existing)
- RTE per line
- Java 2 JRE
Central Database/Web Server
- MS SQL
- Tomcat
- Factory Configuration
- Ja va 2 JR E
Report Generation:
- MSXM
- Excel
all databases, all line
databases
3 Installing SIPLACE Explorer Installation and Configuration Guide SIPLACE Explorer
3.1 Initial Installation of SIPLACE Explorer 2.0 SP1 Edition 12/2005 EN
28
3.1.1.4 Island Installation
In this installation variant, SIPLACE Explorer with all system components can be installed on the
existing SIPLACE line server.
3
Software Requirements SIPLACE Line Server:
– System environment - one of the following versions:
– Windows 2000 Workstation with SP3 or SP4
– Windows XP Professional with SP2
– MSDE 2000
– Explorer installation:
– Runtime Environment
– Tomcat Web server
– Java 2 JRE
– Factory Configuration
3
Hardware Requirements SIPLACE Line Server:
– all requirements of the existing SIPLACE Line Server
– Computer with 2.4 GHZ CPU
– 2 GB memory
– 10 GB available hard drive capacity
3
NOTE
Please note that one line can only be used for one application in this installation variant. 3
