Installation and Configuration Guide SIPLACE Explorer 3 Installing SIPLACE Explorer

Edition 12/2005 EN 3.1 Initial Installation of SIPLACE Explorer 2.0 SP1

Fig. 3 - 2 Installation variants: Line

only for 1 application

per line

SIPLACE Line Server

(existing)

- RTE per line

- Java 2 JRE

Central Database/Web Server

- MS SQL

- Tomcat

- Factory Configuration

- Ja va 2 JR E

Report Generation:

- MSXM

- Excel

all databases, all line

databases

3 Installing SIPLACE Explorer Installation and Configuration Guide SIPLACE Explorer

3.1 Initial Installation of SIPLACE Explorer 2.0 SP1 Edition 12/2005 EN

3.1.1.4 Island Installation

In this installation variant, SIPLACE Explorer with all system components can be installed on the

existing SIPLACE line server.

Software Requirements SIPLACE Line Server:

– System environment - one of the following versions:

– Windows 2000 Workstation with SP3 or SP4

– Windows XP Professional with SP2

– MSDE 2000

– Explorer installation:

– Runtime Environment

– Tomcat Web server

– Java 2 JRE

– Factory Configuration

Hardware Requirements SIPLACE Line Server:

– all requirements of the existing SIPLACE Line Server

– Computer with 2.4 GHZ CPU

– 2 GB memory

– 10 GB available hard drive capacity

NOTE

Please note that one line can only be used for one application in this installation variant. 3
