Installation and Configuration Guide SIPLACE Explorer 3 Installing SIPLACE Explorer

Edition 12/2005 EN 3.2 Update-Installation of SIPLACE Explorer 2.0 SP1

3.2.1 SIPLACE Explorer 2.0 SP1 - Update Installation

NOTE

You must have Windows 2000 administrator privileges to perform installation. 3

→ Place the SIPLACE Explorer CD in your CD-ROM drive. The Start screen will appear.

Fig. 3 - 38 SIPLACE Explorer setup - Start Screen

→ Select SIPLACE Explorer 2.0 SP1.

3 Installing SIPLACE Explorer Installation and Configuration Guide SIPLACE Explorer

3.2 Update-Installation of SIPLACE Explorer 2.0 SP1 Edition 12/2005 EN

→ You will be guided through the SIPLACE Explorer installation procedure.

Fig. 3 - 39 SIPLACE Explorer welcome

→ Exit all other programs and then click on Next.

→ To run SIPLACE Explorer you need to have JAVA 2 JRE v.1.5 installed on your PC. If it is

already installed on your PC, installation will begin automatically.

→ However, if the installation procedure is unable to find J2 JRE v.1.5.X, the Locate J2SDK

dialog box will appear on your screen.

Fig. 3 - 40 SIPLACE Explorer setup - locate JAVA 2 SDK

Installation and Configuration Guide SIPLACE Explorer 3 Installing SIPLACE Explorer

Edition 12/2005 EN 3.2 Update-Installation of SIPLACE Explorer 2.0 SP1

→ In this case, you can either enter the path to the J2SDK 2 JRE v.1.5. folder directly into the text

field or click on the

Browse button and use the Open File dialog box to find the JAVA 2 JRE

folder.

→ If you failed to correctly specify the path to the folder in which JAVA 2 SDK is installed, you will

see the following dialog box.

Fig. 3 - 41 SIPLACE Explorer setup - unable to locate J2SE

→ Click OK to return to the previous screen. SIPLACE Explorer requires JAVA 2 JRE to be

installed prior to installation.

→ At this point, you can either try to specify the JAVA 2 JRE folder again, or click Cancel to exit

the installation of SIPLACE Explorer.

→ If you chose Cancel, please install the version of JAVA 2 JRE included on the installation CD

or available free from (see page 29) Sun Microsystems at http://java.sun.com/j2se and then re-

start installation of SIPLACE Explorer.

NOTE

If you have the J2 Runtime environment (not JAVA 2 JRE) - available from Sun Microsystems

at http://java.sun.com/j2se - installed on your system, the website generated by SIPLACE

Explorer Website Builder will not function properly as it is based on JSP, which requires JAVA

2 JRE. 3

→ The installation of SIPLACE Explorer 2.0 SP1 will be continued once JAVA 2 JRE v.1.5 has

been localized. The following dialog box will appear.
