Page +$1:+$ 73 SM481 PLUS Long Conveyor Ass’y 1500mm(4/4) NO. Lev . PA R T N O . P ART NAME Q'TY Old No. Supply Refere nce
Page
+$1:+$
72
SM481
PLUS
Long Conveyor Ass’y 1500mm(4/4)
NO. Lev. PART NO. PART NAME Q'TY Old No. Screw Reference
28 MC05-900026 TIMING BELT [258-3M-9] 1
S1 FC18-902761 SOCKET HEAD CAP SCREW M5*20 (NI/ZN)
S2 FC18-902741 SOCKET HEAD CAP SCREW M4*10 (NI/ZN)
S3 FC18-902757 SOCKET HEAD CAP SCREW M5*15 (NI/ZN)
S4 FC18-902722 SOCKET HEAD CAP SCREW M3*8 (NI/ZN)
S5 FC18-902745 SOCKET HEAD CAP SCREW M4*15 (NI/ZN)
S6 FC18-902751 SOCKET HEAD CAP SCREW M4*35 (NI/ZN)
S7 FC18-902728 SOCKET HEAD CAP SCREW M3*12 (NI/ZN)
Page
+$1:+$
73
SM481
PLUS
Long Conveyor Ass’y 1500mm(4/4)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Reference
Page
+$1:+$
74
SM481
PLUS
Head Ass’y(1/5)
1
6
7
10
11
4
4
5
3
2
16
16
13
8
9
12
12
14
15
