ACT with SSW 7xx / User Manual 07/2017 Edition 11 2.3.2 Individual Component s in the ACT Set Measuring plate (glass plate) in met al frame ( Figur e 2 -1 and Figure 2 -2 ): The glass compone nts and the measuri ng plate…
ACT with SSW 7xx / User Manual 07/2017 Edition
10
NOTICE
1)
Optional glass components CC07-500
The optional CC07-500 glass components, item no. [00338000-02] were offered as
option for measuring the SST25 (FC camera) up to station software version 707.1.
As of station software version 707.1 and SIPLACE Pro 11.x, this component is not
supported anymore.
Instead, a component description CC02-05_FC is available in SIPLACE Pro as of
version 11.x.
ACT with SSW 7xx / User Manual 07/2017 Edition
11
2.3.2 Individual Components in the ACT Set
Measuring plate (glass plate) in metal frame (Figure 2-1 and Figure 2-2):
The glass components and the measuring plate are kept in a storage case.
Figure 2-1: Storage case for measuring plate Figure 2-2: Storage case for glass components
The glass components used for ACT are placed in the milled divisions in the waffle pack tray
(Abbildung 2-3).
Figure 2-3: Waffle pack tray for glass components
Key:
(1) Waffle pack tray
(2) Waffle pack tray carrier
(3) Glass components
ACT with SSW 7xx / User Manual 07/2017 Edition
12
Figure 2-4: Manual waffle pack tray holder for X-table (carrier) for the glass components
Figure 2-5: Measuring plate for ACT
