ACT with SSW 7xx / User Manual 07/2017 Edition 32 Optional ACT programs for Tray in Conveyor as of SIPLACE Pro 11.1 Machine Head Camera Nozzle Conv ey or P lacement P rog ram X-/SX-/DX- series, X-series S; TX; TH -IC, P&…

100%1 / 220
ACT with SSW 7xx / User Manual 07/2017 Edition
31
4.1.1.2 Placement Program Overview for SIPLACE Pro ≥ 11.x ≤ 13.1
Station software version 706.02.SP1 Hotfix 2 or 707.1.SP1 Hotfix 2 or higher.
Standard ACT programs
Table 4-2: Assignment of machine, board, head as of SIPLACE Pro 11.x
1)
As of software SIPLACE Pro 11.x with station software version 706.02.SP1 Hotfix 2 or 707.1.SP1 Hotfix 2 or higher,
the CC02-05 component (with QFP structure) is used for the SST 25 camera (Flip-Chip camera).
The CC07-500 glasscomponent (with QFP structure) is not supported anymore. If the CC07-500 component is already
available and still to be used for measuring the SST 25 camera, the corresponding board with its component and
component shape data and the tables can be selectively imported from the *.sipro files of the SIPLACE Pro 9 version.
This data can be obtained from the Software License Portal or via the hotline.
2)
As of software SIPLACE Pro 11.x with station software version 706.02.SP1 Hotfix 2 or 707.1.SP1 Hotfix 2 or higher.
From this version, a separate board description is available for all Pick & Place heads in which the CPP head has now
been integrated for the P&P mode.
3)
For machines requiring higher precision, such as CA machines and X S Micron, separate high precision programs with
high precision Cerampads are available for measuring the C&P20 heads. As of the software versions mentioned
above, it is possible to enable a Precision parameter in the component shape description.
4)
Machine type E by SIPLACE, as of station software version 708.0.
5)
For compatibility with older station software versions. If SIPLACE Pro has been updated without updating the station
software, the machine verification of CPP heads in P&P mode can be performed anyway with this program.
6. As of SIPLACE Pro version 11.1, board descriptions for using the Tray in Conveyor for ACT option are available, see
chapter 5.
ACT with SSW 7xx / User Manual 07/2017 Edition
32
Optional ACT programs for Tray in Conveyor as of SIPLACE Pro 11.1
Machine Head Camera Nozzle Conveyor Placement Program
X-/SX-/DX-
series,
X-series S; TX;
TH-IC,
P&P-IC,
CPP (P&P mode)
SST 33,
SST 36
518 / 2057 Single
ACT_CC02-
05_PP_ConveyorTray left
(48 x CC02-05)
Tray + ACT board connected with
adapter in single conveyor mode.
The tray is mounted to the left of the
glass plate.
X-/SX-/DX-
series,
X-series S; TX;
TH-IC,
P&P-IC,
CPP (P&P mode)
SST 33,
SST 36
518 / 2057 Single
ACT_CC02-
05_PP_ConveyorTray right
(48 x CC02-05)
Tray + ACT board connected with
adapter in single conveyor mode.
The tray is mounted to the right of the
glass plate.
X-/SX-/DX-
series,
X-series S; TX;
TH-IC,
P&P-IC,
CPP (P&P mode)
SST 25, 518 Single
ACT_CC02-
05_FC_ConveyorTray left
(48 x CC02-05)
Tray + ACT board connected with
adapter in single conveyor mode.
The tray is mounted to the left of the
glass plate.
X-/SX-/DX-
series,
X-series S; TX;
TH-IC,
P&P-IC,
CPP (P&P mode)
SST 25 518 Single
ACT_CC02-
05_FC_ConveyorTray right
(48 x CC02-05)
Tray + ACT board connected with
adapter in single conveyor mode.
The tray is mounted to the right of the
glass plate.
X-/SX-/DX-
series,
X-series S; TX;
TH-IC,
P&P-IC,
CPP (P&P mode)
All All Dual
ACT_Spacer in other Lane for
Conveyor Tray
For a job in dual lane synchronous
mode, this empty board is specified in
the lane in which the tray shall be
transported.
Table 4-3: Optional ACT programs for Tray in Conveyor as of SIPLACE Pro version 11.1
ACT with SSW 7xx / User Manual 07/2017 Edition
33
Optional ACT programs for LED Centering as of SIPLACE Pro 12.1
Machine Head Camera Nozzle Placement Program
SX Series 1 x CPP SST47 2004
ACT_1x CPP_LED-Centering G1
(96 x Cerampad)
SX Series 1 x CPP SST47 2004
ACT_1x CPP_LED-Centering G2
(96 x Cerampad)
SX Series 2 x CPP SST47 2004
ACT_2x CPP_LED-Centering
(2 x 96 x Cerampad)
Table 4-4: Optional ACT programs for LED Centering as of SIPLACE Pro version 12.1
4.1.1.3 Placement Program Overview for TX micron, CA (High Accuracy)
Station software version as of 710.0 and SIPLACE Pro ≥ 14.0
ACT programs for placement machines with high accuracy classes
Table 4-5: ACT programs for placement machines with high accuracy classes as of SIPLACE Pro version 14.0
