Dispenser Accessories
“Your dispensers work great. Making dots
used to be an art. Now we don't even think
about it. We just fill the barrels and go.”
– Preferred Technical Group
PART # ACCESSORY DESCRIPTION UltimusPlus
Performus
I-II V X
Flex arm syringe barrel holder
Mounts to dispenser cabinet; can be adjusted
to multiple positions
3
3
3
3
Optimeter – 30cc size
Optimeter – 10cc size
Syringe barrel adapter that maintains consistent
full-to-empty pressure on uid being dispensed
3
3
Finger switch
(Rectangular connector)
Finger switch
(Round DIN connector)
Low voltage, push-button nger switch controls
dispense cycle
3
3
3 3
Syringe barrel production stand
Provides full-barrel swivel, horizontal, and vertical
adjustment. Accepts all EFD barrels.
3 3 3 3
8-pin I/O connector assembly Allows easy connection to dispenser for external control
3 3
Cleanroom lter mufer
Filters output air to meet Fed 209-B
(0.5 micron particulates)
3 3 3
VacTweezer
™
pickup tool
Useful, low cost pick-and-place tool with staticide
treated kit. Includes (7) tips, (5) pad sizes
3 3 3 3
Dispensing tip sample kit
Includes a selection of various types and styles of
dispensing tips
3 3 3 3
5-micron lter/regulator
Provides proper air ltering for all dispensers. Order if
you do not have a clean, dry, ltered factory air supply.
3 3 3 3
5-micron lter/regulator with
coalescing lter
5-micron lter/regulator with coalescing lter
3 3 3 3
Coalescing lter assembly only Recommended for systems dispensing cyanoacrylates
3 3 3 3
Filter element replacement kit Removes liquid aerosols from air supply
3 3 3 3
Barcode scanner
Scans barcode and automatically alternates
between programs
3
Ultimus
9
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Portable Dispensers
HPD Hand Plungers
DispensGun
Versatile and inexpensive, manual dispensers are ideal for touch-ups, low-volume
assembly, and eld work. They can be used with all EFD syringe barrels, pistons, and tips.
HPD
Designed for use with EFD syringe barrels and pistons, HPD
™
Hand Plungers provide
a clean, comfortable alternative to squeeze bottles and hand syringes.
DispensGun
®
Features 10:1 mechanical leverage that makes it easy to dispense thick materials like
greases and silicones without hand fatigue. A clean cutoff when the trigger is released
prevents oozing between uid applications.
Features and Benets
• Ergonomic design
• Fatigue-free dispensing of thick uids
• Positive shutoff, no dripping
• Simplied maintenance
• Reusable
7023615 HPD3K Hand Plunger
3cc syringe barrel size
7023622 HPD5 Hand Plunger
5cc syringe barrel size
7023610 HPD30K Hand Plunger
30cc syringe barrel size
7023133 DG3 DispensGun
3cc syringe barrel size
7023137 DG5 DispensGun
5cc syringe barrel size
7023125 DG10 DispensGun
10cc syringe barrel size
7023134 DG30 DispensGun
30cc syringe barrel size
7023141 DG55 DispensGun
55cc syringe barrel size
Fluids
MODELS
DG HPD
Anaerobics
s s
Coatings
l l
Cyanoacrylates X X
Gel Cyanoacrylates
s s
White Glues
l l
Epoxies
l l
Inks X
l
Greases
l l
Oils X
s
Sealants
l l
Silicones
l l
Solder/Braze Pastes
l l
Solvents X X
UV Cure
l l
Key
l Recommended
s Satisfactory
X Do not use
HPD DispensGun
2K Dispense Guns
See 2K Dispense Guns for dispensing
2-component materials.
“Production doubled the first day the EFD
systems were installed.”
– Food Packaging Group
10
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Productivity Tools
HPx High-Pressure
Dispensing Tool
The HP
™
Series high-pressure dispensing
tool applies RTV silicones, epoxies,
medical adhesives, and other thick uids
through dispensing tips as small as
0.004" in diameter. Designed to work
with EFD air-powered dispensers, these
tools will multiply the output of a standard
100 psi dispenser up to 7x.
Features and Benets
• Fast, fatigue-free application of thick uids
• Aluminum handpiece is easy to hold
• Easy tip installation/removal with built-in wrench
• Low uid level indicator
7023590 HP3cc Dispensing Tool
Uses 3cc EFD syringe barrels and pistons and
produces a maximum pressure of 700 psi
(48.2 bar).
7015289 HP5cc Dispensing Tool
Uses 5cc EFD syringe barrels and pistons and
produces a maximum pressure of 400 psi (27.6 bar).
7012598 HP10cc Dispensing Tool
Uses 10cc EFD syringe barrels and pistons and
produces a maximum pressure of 400 psi (27.6 bar).
www.nordsonefd.com/HPXTool
The pneumatically operated Equalizer
™
2K dispensing tool makes it possible to
dispense accurate, repeatable amounts
of 2-component materials. It is designed
for use with EFD dispensers and 50mL
Side x Side cartridges and static mixers
(order separately).
Equalizer 2K
Dispensing Tool
7360152
Standard configuration provides accurate 50mL 1:1
and 2:1 dispensing.
7015875
Kit Universal Stand Mount 25−50 mm.
