Thermal Compounds
Thermal Compounds
Non-silicone thermal compounds are used in a wide range of electronic and
electromechanical applications because they are resistant to thermal cycling
degredation. Thermal compounds are formulated to provide excellent heat transfer.
They are non-hazardous, and are RoHS and REACH compliant (lead-free). Their long
shelf-life stability ensures that they will not dry, harden, or melt in normal use.
For challenging applications, thermal compounds are available with specialty features.
Choosing the best thermal compound requires some understanding of the mechanics
of heat transfer and how the thickness of the thermal compound layer, the bond line
thickness, inuences product choice.
SPECIFICATIONS
Formula
52022 52054 53054 52055* 52050 52160 53053
Specic Gravity at 25° C
2.7 3.0 3.0 2.8 2.6 2.6 2.8
Bleed: 24 Hrs., % Weight
0.1 0.0 0.01 0.0 0.01 0.3 0.3
Evaporation: 150C, 24 Hrs., %Weight
0.15 <2.0 <2.0 1.0 0.6 0.5 0.5
Thermal Conductivity: W/m-K
0.92 1.3 1.6 1.3 3.8 2 3.5
Dielectric Strength: V/mil
305 265 265 265 351 n/a 318
Dielectric Constant: 25° C, 1000Hz
4.5 5.02 5.02 5.02 4.92 n/a 5
Dissipation Factor: 25° C, 1000Hz
0.0029 0.0022 0.0022 0.0022 0.0032 n/a 0.0027
Volume Resistivity: Ohm-cm
1.65x10^14 2.0x10^15 2.0x10^15 2.0x10^15 1.0x10^13 over current 2.15x10^15
Operating Temperature: ° C
-40 to 200 -40 to 180 -40 to 180 0 to 180 -40 to 200 -40 to 200 -40 to 200
Flow Rate: g/min
4 to 7 8 to 9 5 to 6 4.5 to 6.5 1 to 3 3 to 8 7 to 9
Minimum Bond Line: mm
0.0381 0.0127 0.0127 0.0127 0.0508 0.0254 0.1270
Viscosity: 25° C kCps
460 470 510 620 350 230 1000
Viscosity: 50° C kCps
400 410 470 550 60 170 400
Appearance
Smooth,
off-white paste
Smooth white
paste
Smooth white
paste
Smooth white
paste
Dark gray paste
Smooth, gray
paste
Off white
paste
Shelf Life
1 year 1 year 1 year 1 year 1 year 1 year 1 year
www.nordsonefd.com/TIM
*Water cleanable for easy clean up
117
Leading the Way in 2K
Nordson EFD’s 2K product line provides static mixers, cartridge
systems, and meter mix valves for reactive two-component (2K)
adhesives & sealants such as epoxies, urethanes, silicones, and
acrylics.
Mixing Solutions
• Two mixer geometries: Spiral and Square
• Complete line of plastic and metal mixers for low- and
high-pressure applications
• Two-component cartridge systems from 1.0 to 1500mL
capacities
• Designed and manufactured in the USA and ISO 9001:2015
certied
• Competitive pricing, high quality, fast delivery, and superior
customer service
Two-Component Dispensing Systems
Cartridges / 2K Dispensers / Mixers / Meter Mix Valves
118
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
2K Cartridges
Side x Side
Cartridge Systems
Nordson EFD offers a comprehensive selection of high-quality, competitively-priced
Side x Side cartridges for packaging and dispensing two-component materials used
in automotive, construction, industrial, medical, and dental applications.
Features and Benets
• Eliminates mess and waste
• Reduces exposure to hazardous resins
• Ensures accurate proportioning and mixing
Cartridge System Outlet Options
Select from two types of Side x Side cartridge outlets:
Open End Outlet
• Pre-assembled with traditional nose plugs and retaining nuts
• Many can be molded in polypropylene (PP) or nylon
• See specic cartridge descriptions or contact EFD for material options
Hermetically-sealed Closed End Outlet
• Features a patented “pry-off” closure
• Molded in one operation
• Cost-effective alternative to open end cartridges
Open End Outlet
Closed End Outlet
PRY-OFF CAP INSTRUCTIONS
• Insert at head of screwdriver into slot and pry upward
• Cap can be re-inserted to seal a partially used cartridge.
To avoid cross contamination, match up the circles and
squares on the cap and top of cartridge body
• For 50mL cartridges, the cap can be easily snapped off
with your thumb and forenger in the same upward motion
“Innovation truly drives the success of the
adhesives and sealants industry, and we
created theASIReaders’ Choice Awards
to celebrate all of the industry’s hard work
and ingenuity. I am thrilled to announce that
Nordson EFD received the most votes in the
Equipment category.”
– ASI Magazine
Continued next page
