143 www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006 Useful Resources Bead Volumes Dot Volumes Volume 1 fluid ounce = 29.57 cubic centimeters 1 gallon = 3…
142
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Useful Resources
Application Videos
Visit our Video Gallery to access 150+ application, how-to, and product videos.
See EFD dispensing solutions in action.
Watch Videos: www.nordsonefd.com/VideoGallery
What Our Customers Say
Find out how Nordson EFD helps manufacturers improve their uid dispensing
processes every day — see what our customers have to say.
Our Customers Know Best: www.nordsonefd.com/Testimonials
Expert Recommendations
Knowledgeable Nordson EFD uid application specialists have, on average, more than
10 years of experience helping customers nd the right dispensing solutions.
Request Expert Advice: www.nordsonefd.com/Advice
Request Lab Test: www.nordsonefd.com/ApplicationTest
Follow our Blog: www.nordsonefd.com/Blog
Easy Part Number Search
It’s easy to search our digital catalog to nd products by part number or keywords.
Plus, get links to product specs, videos, and more. With our app, you can even access
the catalog from your smartphone.
Find Part Numbers: www.nordsonefd.com/Digital-Catalog
Machine Builder Guide & CAD Models
When you partner with Nordson EFD, you benet from a wide range of reliable, best-in-
class precision uid dispensing solutions.
Learn more: www.nordsonefd.com/MachineBuilderGuide
Download CAD models: www.nordsonefd.com/CAD
Choosing and implementing the best possible uid dispensing equipment starts with access to the best possible
resources. Here are some to get you started:
143
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Useful Resources
Bead Volumes
Dot Volumes
Volume
1 fluid ounce = 29.57 cubic centimeters
1 gallon = 3785 cubic centimeters
1 gallon = 3.785 liters
1 gallon = 128 fluid ounces
1 gallon = 4 quarts
1 gallon = 8 pints
1 gallon = 16 cups
1 gallon = 231 cubic inches
1 gallon = 0.134 cubic feet
1 liter = 0.264 gallons
1 liter = 1.06 quarts
1 liter = 1000 milliliters
1 cubic foot = 1728 cubic inches
1 cubic foot = 7.48 gallons
1 cubic inch = 16.387 cubic centimeters
1 cubic centimeter = 1 milliliter
1 microliter = 0.001 cc’s
1 microliter = 1000 nanoliters
1 nanoliter = 0.000001 cc’s
1 nanoliter = 1000 picoliters
Weight
1 kilogram = 1000 grams
1 kilogram = 2.2 pounds
1 pound = 16 ounces
1 pound = 453.6 grams
1 pound = 7000 grains
1 ounce = 28.35 grams
Length
1 micron = .0000394 inches
1 micron = 0.001 millimeters
1 centimeter = 10 millimeters
1 centimeter = 10,000 microns
1 inch = 2.54 centimeters
1 inch = 25.4 millimeters
1 inch = 25,400 microns
1 foot = 30.48 centimeters
1 yard = 91.44 centimeters
1 mile = 5280 feet
1 mile = 1.6 kilometers
Pressure
1 psi = 0.069 bar
1 psi = 0.070 kgf/cm
2
1 psi = 6894.8 Pa
1 psi = 27.680 in H
2
0@4° C
Volumes and
Conversions
Volume of Beads
Bead diameter Volume per linear inch
mm inches cubic inch cc’s
1.6 0.06 0.0031 0.050
2.4 0.09 0.0069 0.113
3.2 0.12 0.0123 0.201
4.8 0.19 0.0276 0.453
Volume of Dots
dot mm inches V cc
0.5 0.02 0.00003
0.8 0.03 0.0001
1.0 0.04 0.0003
1.3 0.05 0.0005
1.8 0.07 0.001
2.3 0.09 0.003
2.8 0.11 0.006
3.3 0.13 0.009
3.8 0.15 0.014
4.3 0.17 0.021
4.8 0.19 0.029
5.6 0.22 0.046
6.1 0.24 0.059
6.6 0.26 0.075
Volume of Dots
dot mm inches V cc
7.6 0.30 0.116
8.9 0.35 0.184
10.2 0.40 0.275
11.4 0.45 0.391
12.7 0.50 0.536
19.1 0.75 1.810
Volume = D
3
x 0.5236 ÷ 2*
(*1/2 the volume of a sphere)
144
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Useful Resources
Conversion Factors
Dispensing conditions are driven by many factors. When selecting the correct
system for your application, the material’s properties, including viscosity and deposit
size, are important considerations.
Viscosity is the measurement of a uid’s internal resistance to ow. This is
usually designated in units of centipoise or poise, but can be expressed in other
measurements as well. Refer to the chart below.
100 Centipoise = 1 Poise
1 Centipoise = 1 mPa
•
s (Millipascal Second)
1 Poise = 0.1 Pa
•
s (Pascal Second)
Centipoise = Centistoke x Density
APPROXIMATE VISCOSITIES OF COMMON MATERIALS
(at room temperature — 21° C (70° F)
Material Viscosity in Centipoise
Water 1 — 5
Kerosene 10
Anti-freeze or Ethylene Glycol 15
Motor Oil SAE10 50 — 100
Motor Oil SAE30 or Maple Syrup 150 — 200
Motor Oil SAE40 or Castor Oil 250 — 500
Motor Oil SAE60 or Glycerin 1,000 — 2,000
Corn Syrup or Honey 2,000 — 3,000
Molasses 5,000 — 10,000
Chocolate Syrup 10,000 — 25,000
Ketchup or Mustard 50,000 — 70,000
Tomato Paste or Peanut Butter 150,000 — 250,000
Shortening or Lard 1,000,000 — 2,000,000
Caulking Compound 5,000,000 — 10,000,000
Window Putty
100,000,000
• RTV/Sealants
• Solder Pastes
• Solvents
• UV-Cure & Light-Cure
• White Glues
Typical Assembly Materials Dispensed with EFD Systems
• Activators
• Anaerobics
• Coatings
• Cyanoacrylates
• Electrolytes
• Epoxies
• Fluxes
• Gels
• Greases
• Lubricants
• Oils
• Marking Inks
Fluid Viscosities
