Useful Resources
Conversion Factors
Dispensing conditions are driven by many factors. When selecting the correct
system for your application, the material’s properties, including viscosity and deposit
size, are important considerations.
Viscosity is the measurement of a uid’s internal resistance to ow. This is
usually designated in units of centipoise or poise, but can be expressed in other
measurements as well. Refer to the chart below.
100 Centipoise = 1 Poise
1 Centipoise = 1 mPa
•
s (Millipascal Second)
1 Poise = 0.1 Pa
•
s (Pascal Second)
Centipoise = Centistoke x Density
APPROXIMATE VISCOSITIES OF COMMON MATERIALS
(at room temperature — 21° C (70° F)
Material Viscosity in Centipoise
Water 1 — 5
Kerosene 10
Anti-freeze or Ethylene Glycol 15
Motor Oil SAE10 50 — 100
Motor Oil SAE30 or Maple Syrup 150 — 200
Motor Oil SAE40 or Castor Oil 250 — 500
Motor Oil SAE60 or Glycerin 1,000 — 2,000
Corn Syrup or Honey 2,000 — 3,000
Molasses 5,000 — 10,000
Chocolate Syrup 10,000 — 25,000
Ketchup or Mustard 50,000 — 70,000
Tomato Paste or Peanut Butter 150,000 — 250,000
Shortening or Lard 1,000,000 — 2,000,000
Caulking Compound 5,000,000 — 10,000,000
Window Putty
100,000,000
• RTV/Sealants
• Solder Pastes
• Solvents
• UV-Cure & Light-Cure
• White Glues
Typical Assembly Materials Dispensed with EFD Systems
• Activators
• Anaerobics
• Coatings
• Cyanoacrylates
• Electrolytes
• Epoxies
• Fluxes
• Gels
• Greases
• Lubricants
• Oils
• Marking Inks
Fluid Viscosities
