Dial-A-Dose
Industrial Syringes
Nordson EFD offers a comprehensive selection of syringes used for uid packagers
in the electronics rework, industrial, dental, and do-it-yourself markets. Dial-A-Dose
®
syringes are an ideal packaging system for controlled placement of adhesives
and sealants. For multi deposit use, EFD Dial-A-Dose syringes offer an innovative,
customizable solution to tailor deposits based on application size and other
requirements.
DIAL-A-DOSE INDUSTRIAL SYRINGES
Syringes include integrated molded nozzle. Order plungers and caps separately. White caps molded in LDPE.
Multi-Dose Plunger Single-Dose Plunger Options
Syringe Size Material Color Cap Dial-A-Dose One-Piece Two-Piece
Nozzle Style: Thin Taper 1/16" ID x 1-1/18" Length
7660277 6cc PE White 7660194 – 7660292 –
7022846 15cc PE White 7660194 7660343 7660329 7660333
Nozzle Style: Luer Lock 1/16" ID x 1/4" Length
7660392 32cc PP Amber 7660246 7660452 – 7660436
Continued next page
For use with:
Adhesives
Epoxies & Silver Epoxies
Greases & Lubricants
Sealants
Solder Pastes
Dial-A-Dose plunger
One-piece plunger
Two-piece plunger
Dial-A-Dose Industrial Syringes
Features and Benets
• Range of sizes, colors, and nozzles
• Self-venting barrels with “lead-in” aid for easy ll
• Single and multi deposit syringes allow manufacturers to make the deposit, cap the
syringe, and save for next deposit
• Locking ring ensures exact amount is dispensed
21
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Dial-A-Dose Syringes
DIAL-A-DOSE INDUSTRIAL SYRINGES
Multi-Dose Plunger Single-Dose Plunger Options
Syringe Size Material Color Cap Dial-A-Dose One-Piece Two-Piece
Nozzle Style: Standard 3/16" ID x 1-13/32" Length
7660313 15cc PE White 7660198 7660343 7660329 7660333
7660399 32cc PE White 7660198 7660452 – 7660436
7660571 100cc PP Clear 7660198 7660580 – 7660581
Nozzle Style: Medium 9/32" ID x 1-13/32" Length
7660419 32cc PE White 7660207 7660452 – 7660436
7660482 34cc PE White 7660207 7660452 – 7660436
Nozzle Style: Cone 3/32" ID x 1-1/2" Length
7660371 30cc PE White 7660201 – 7660380 –
Nozzle Style: Medium 1/4" ID x 1-23/64" Length
7660552 80cc PE White 7660207 7660557 – 7660938
Nozzle Style: Wide 13/32" ID x 1-5/16" Length
7660522 60cc PE White 7660191 7660538 – 7660528
7660553 80cc PE White 7660191 7660557 – 7660938
7660572 100cc PE White 7660191 7660580 – 7660581
From previous page
22
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Optimum Cartridge Systems
Push-in air line connector
End cap
Locking tabs
Detent for locking tab
in cap
Ergonomic grips for
cap installation
Clear retainer for easy
visual monitoring
Retainer
Cartridge
Self-venting outlet cap
0º taper cartridge
Piston channels help
dissipate air during lling
Optimum cartridges and retainers have been designed to function as a complete,
integrated system that improves yields and reduces costs in uid packaging and
dispensing processes.
Cartridge systems are designed for applications that require a reservoir larger than a
70cc syringe barrel. They are available in 2.5 oz, 6 oz, 12 oz, 20 oz, and 32 oz
capacities, and can be used to make timed or visual deposits.
Features and Benets
• Exceptional clarity to allow visual conrmation of uid levels
• High-impact strength and dimensional stability
• ZeroDraft
™
design ensures that internal diameter is
consistent from top to bottom
• Excellent chemical compatibility with a wide range of uids
• Available in clear, black, amber, and white
• White cartridges are molded from a proprietary blend and have
better frozen temperature resistance
