Optimum Cartridge Systems
RETAINER SYSTEMS
Retainer Systems* Retainer Bodies
Part # Size Part # Size
7012430 2.5 oz (75 ml) 7013857 2.5 oz (75 ml)
7012433 6 oz (180 ml) 7013858 6 oz (180 ml)
7012436 12 oz (360 ml) 7013859 12 oz (360 ml)
7012439 20 oz (600 ml) 7013860 20 oz (600 ml)
7013899 32 oz (960 ml) 7013900 32 oz (960 ml)
Retainer Cap Assemblies
Part # Size
7012531 2.5, 6, 12 oz (75, 180, 360 ml)
7012532 20, 32 oz (600, 960 ml)
Retainer Cap O-Ring Kits (2/pkg.)
Part # Material Size
7014373 Buna 2.5, 6, 12 oz (75, 180, 360 ml)
7026914 EPR 2.5, 6, 12 oz (75, 180, 360 ml)
7014372 Buna 20, 32 oz (600, 960 ml)
7026916 EPR 20, 32 oz (600, 960 ml)
7026917 Viton 20, 32 oz (600, 960 ml)
Optimum cartridge retainers are molded from high-tensile, claried resin that permits
easy visual monitoring of uid levels. Large textured ribs provide an ergonomic grip for
cap installation.
Retainer caps feature locking tabs that snap securely into detents on the retainer
body with an audible click. A push-in air line connector on top of the cap eliminates
the need for bayonet connectors.
*The retainer cap O-rings are available in three different materials. Please select the one most compatible
with your uid. Standard O-ring material is Buna.
Cartridge Retainer
Systems
“EFD is our favorite vendor to deal with –
fast, professional, and top notch products.”
– Contract Packager
25
7018646
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Cartridge Retainer
Systems with Regulators
Optimum Cartridge Systems
Nordson EFD precision, constant-bleed pressure regulators ensure consistent liquid
pressurizing for consistent uid dispensing results.
Cartridge retainers systems with 7.0 bar (100 psi) pressure regulators include a
cartridge retainer, retainer cap, 1.5 m (5 ft) of 6 mm (0.24") OD polyethylene feed
tubing, and all necessary ttings.
Should your application require a 1.0 bar (15 psi) pressure regulator, please purchase
your cartridge retainer system and pressure regulator separately. All retainer systems
include the cartridge retainer, cap, tubing, and ttings.
RETAINER SYSTEMS WITH 7.0 BAR (100 PSI) REGULATORS
Part # Size Description
7012432 2.5 oz (75 ml) Retainer system with 7.0 bar (100 psi) regulator
7012435 6 oz (180 ml) Retainer system with 7.0 bar (100 psi) regulator
7012438 12 oz (360 ml) Retainer system with 7.0 bar (100 psi) regulator
7012440 20 oz (600 ml) Retainer system with 7.0 bar (100 psi) regulator
7014100 32 oz (960 ml) Retainer system with 7.0 bar (100 psi) regulator
RETAINER SYSTEMS AND 1.0 BAR (15 PSI) REGULATORS
Part # Size Description
7012430 2.5 oz (75 ml) Retainer system
7012433 6 oz (180 ml) Retainer system
7012436 12 oz (360 ml) Retainer system
7012439 20 oz (600 ml) Retainer system
7013899 32 oz (960 ml) Retainer system
7020585 – 1.0 bar (15 psi) regulator (sold separately)
1/10 GALLON CARTRIDGE ASSEMBLY WITH REGULATOR
Part # Size Description
1/10 gal (300 ml) Cartridge assembly for caulking tubes with 7.0 bar (100 psi) regulator
26
Updated
Obsoletion
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Optimum Cartridge Systems
Optimum pistons are precision molded from high-density
polyethylene. The consistent t perfectly matches cartridge walls
for smooth, unobstructed travel and ensures consistent results in
uid packaging and dispensing processes.
Unique channels help dissipate air during the lling process,
reducing or eliminating the need to centrifuge. Dual wiping edges
eliminate waste and residue to lower production costs and
simplify disposal of used cartridges.
Blue pistons have a smaller leading edge wiper. The looser t
reduces dripping or stringing during the dispensing of very thick
uids and the color makes it easy to see the piston position inside
the cartridge.
End caps snap securely over cartridge anges to prevent leaks
and uid contamination. The center push-button presses the cap
against the cartridge wall to form a positive, airtight seal.
Self-venting outlet caps feature a large ribbed gripping area that
simplies manual installation, along with precision molded threads
and a tapered seat that provides a snug, leakproof seal.
Cartridge Pistons
Cartridge
End/Outlet Caps
CARTRIDGE END CAPS
Part # Size Color Qty/Box
7012423
2.5, 6, 12 oz
(75, 180, 360 ml)
Blue 25
7012424
2.5, 6, 12 oz
(75, 180, 360 ml)
Blue 250
7012425
20, 32 oz
(600, 960 ml)
Blue 10
7012426
20, 32 oz
(600, 960 ml)
Blue 100
CARTRIDGE OUTLET CAPS
Part # Size Color Qty/Box
7012427* All Blue 25
7012428* All Blue 250
CARTRIDGE PISTONS
Part # Size Color Qty/Box
7012419
2.5, 6, 12 oz
(75, 180, 360 ml)
White 25
7012420
2.5, 6, 12 oz
(75, 180, 360 ml)
White 250
7362087
2.5, 6, 12 oz
(75, 180, 360 ml)
Blue 25
7362086
2.5, 6, 12 oz
(75, 180, 360 ml)
Blue 250
7012421
20, 32 oz
(600, 960 ml)
White 10
7012422
20, 32 oz
(600, 960 ml)
White 100
*Tighten to: 13.6 N•m (10 ft-lb)
