Cartridge Retainer
Systems with Regulators
Optimum Cartridge Systems
Nordson EFD precision, constant-bleed pressure regulators ensure consistent liquid
pressurizing for consistent uid dispensing results.
Cartridge retainers systems with 7.0 bar (100 psi) pressure regulators include a
cartridge retainer, retainer cap, 1.5 m (5 ft) of 6 mm (0.24") OD polyethylene feed
tubing, and all necessary ttings.
Should your application require a 1.0 bar (15 psi) pressure regulator, please purchase
your cartridge retainer system and pressure regulator separately. All retainer systems
include the cartridge retainer, cap, tubing, and ttings.
RETAINER SYSTEMS WITH 7.0 BAR (100 PSI) REGULATORS
Part # Size Description
7012432 2.5 oz (75 ml) Retainer system with 7.0 bar (100 psi) regulator
7012435 6 oz (180 ml) Retainer system with 7.0 bar (100 psi) regulator
7012438 12 oz (360 ml) Retainer system with 7.0 bar (100 psi) regulator
7012440 20 oz (600 ml) Retainer system with 7.0 bar (100 psi) regulator
7014100 32 oz (960 ml) Retainer system with 7.0 bar (100 psi) regulator
RETAINER SYSTEMS AND 1.0 BAR (15 PSI) REGULATORS
Part # Size Description
7012430 2.5 oz (75 ml) Retainer system
7012433 6 oz (180 ml) Retainer system
7012436 12 oz (360 ml) Retainer system
7012439 20 oz (600 ml) Retainer system
7013899 32 oz (960 ml) Retainer system
7020585 – 1.0 bar (15 psi) regulator (sold separately)
1/10 GALLON CARTRIDGE ASSEMBLY WITH REGULATOR
Part # Size Description
1/10 gal (300 ml) Cartridge assembly for caulking tubes with 7.0 bar (100 psi) regulator
26
Updated
Obsoletion
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Optimum Cartridge Systems
Optimum pistons are precision molded from high-density
polyethylene. The consistent t perfectly matches cartridge walls
for smooth, unobstructed travel and ensures consistent results in
uid packaging and dispensing processes.
Unique channels help dissipate air during the lling process,
reducing or eliminating the need to centrifuge. Dual wiping edges
eliminate waste and residue to lower production costs and
simplify disposal of used cartridges.
Blue pistons have a smaller leading edge wiper. The looser t
reduces dripping or stringing during the dispensing of very thick
uids and the color makes it easy to see the piston position inside
the cartridge.
End caps snap securely over cartridge anges to prevent leaks
and uid contamination. The center push-button presses the cap
against the cartridge wall to form a positive, airtight seal.
Self-venting outlet caps feature a large ribbed gripping area that
simplies manual installation, along with precision molded threads
and a tapered seat that provides a snug, leakproof seal.
Cartridge Pistons
Cartridge
End/Outlet Caps
CARTRIDGE END CAPS
Part # Size Color Qty/Box
7012423
2.5, 6, 12 oz
(75, 180, 360 ml)
Blue 25
7012424
2.5, 6, 12 oz
(75, 180, 360 ml)
Blue 250
7012425
20, 32 oz
(600, 960 ml)
Blue 10
7012426
20, 32 oz
(600, 960 ml)
Blue 100
CARTRIDGE OUTLET CAPS
Part # Size Color Qty/Box
7012427* All Blue 25
7012428* All Blue 250
CARTRIDGE PISTONS
Part # Size Color Qty/Box
7012419
2.5, 6, 12 oz
(75, 180, 360 ml)
White 25
7012420
2.5, 6, 12 oz
(75, 180, 360 ml)
White 250
7362087
2.5, 6, 12 oz
(75, 180, 360 ml)
Blue 25
7362086
2.5, 6, 12 oz
(75, 180, 360 ml)
Blue 250
7012421
20, 32 oz
(600, 960 ml)
White 10
7012422
20, 32 oz
(600, 960 ml)
White 100
*Tighten to: 13.6 N•m (10 ft-lb)
27
www.nordsonefd.com/TipAdvice
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Precision Dispensing Tips
EFD produces the highest quality dispensing tips in the industry. All tips are produced
in our own silicone-free facilities and subjected to stringent quality control inspections
throughout the entire manufacturing process.
Optimum
Dispensing Tips
Features and Benets
• Free of ash, burrs, and contaminants
• Package labels include lot numbers for process control and traceability
• Consistent from style to style and lot to lot
• 360° SafetyLok
™
thread ensures safe, positive attachment to syringe barrel
• Engineered hub ats for easy twist on, twist off
Available in multiple styles:
Precision Stainless Steel Passivated stainless steel tips handle a wide range of uids
and applications.
Tapered Smooth ow for application of medium- to high-viscosity uids — especially
thick or particle-lled materials like epoxies, RTVs, and braze pastes.
Flexible Polypropylene shafts reach into hard-to-access areas and will not scratch
delicate surfaces. Easily cut to size or angled as needed.
Angled Stainless steel tips available with 45º and 90º bends. Custom bends available.
Brush For spreading glues and greases. Available with soft or stiff bristles.
Specialty For specic applications: Chamfered, PTFE-coated
and PTFE-lined, microdot tips, and oval tips.
Ceramic MicroDot For precise micro-deposits as small as 100 μm. Compatible with
wide range of uids, even ne particle-lled materials.
Precision Nozzle For tight tolerance micro-dispensing in CCM, LED, semiconductor,
and other high-precision industries.
DISPENSING TIP SAMPLE KIT
Part # Description
7013229
Includes a selection of various types and styles of dispensing
tips, pistons, tip and end caps — 150+ pieces
“EFD components are more durable than
others we have used. We have never
encountered a problem with EFD tips and
syringes, and that's saying a lot.”
– Magnavox
