35 CONTROLLER FEA TURES V AL VE CONTROLLERS PICO T oµch / XP V200 8000 8040 7160RA 7194 7100 7140 Jet Valve Control Jet Valve Control Multi Valve Control Multi Spray Valve Control Radial Spinner/ Spray Valve Control Auge…
34
VALVE
FEATURES
VALVES
PICO Pµlse /
Pµlse XP
Liquidyn
702M-SS 725DA-SS 725HF-SS 725HF-A 736HPA-NV xQR41 / V
741V / MD
752V-SS 752V-UHSS 754V-SS
781Mini
787MS-SS
781S-SS 782RA 7860C-RS
794
794-TC
Adjustable uid ow
P
P-Jet
P P
— — —
P P P P P P P
—
P
Air cutoff
—
P
— — — — — — — — —
P P P P
—
Cycle rate ≥ 150Hz 1000Hz
1
P-Jet
P-Dot
— — — — — — — — — — — — — —
Fail-safe
normally closed
—
P P P P P P P P P P P P P
— —
FDA-compliant
wetted parts
— —
P P P P
—
P P P P P P
—
P
—
Fluid body
303 SS
6
303 SS
6
303 SS 303 SS 303 SS Acetal 303 SS 303 SS
4
Acetal
7
UHMW
2
/
7
316L 303 SS 303 SS — —
440C /
Tungsten
Carbide
Modular design
P P
— — — — — xQR41 / V — — —
P
5
— — — —
Quick Release
maintenance
P
— — — — — — xQR41 / V — — —
P
5
— — —
P
Small form factor
— —
P
— — — — xQR41 / V — — —
P
5
— — — —
Snuff-back cutoff
— — —
P P P P
— — — — — — — —
P
Stroke control
reference
— —
P
— — — —
P P P P P P P
— —
Tamper-resistant
stroke control
— —
P
— — — —
°
3
°
P P
—
° °
— —
UHMW
2
polymer
diaphragm
— —
P P P P
— —
P P
PTFE — — — — —
303 stainless
steel air cylinder
— —
P
— — —
P
xQR41
741V-SS
P P
316L
P P
— — —
1
With approved conditional settings
2
Ultra High Molecular Weight polyethylene
3
741V-SS model only
4
Available with PEEK uid body for xQR41 model only
5
781Mini model only
6
Available with PEEK uid body for PICO Pµlse, P-Dot, and P-Jet
7
Optional stainless steel uid body
20
0
5
20
0
5
20
0
5
20
0
5
P
Applicable |
°
Optional | — Not applicable
35
CONTROLLER
FEATURES
VALVE CONTROLLERS
PICO Toµch / XP V200 8000 8040 7160RA 7194 7100 7140
Jet Valve Control Jet Valve Control Multi Valve Control
Multi Spray
Valve Control
Radial Spinner/
Spray Valve Control
Auger Valve Control Dispense Valve Control Spray Valve Control
Recommended valve(s) PICO Pµlse / XP
P-Jet,
P-Dot
702, 725, 736, 741,
752, 754, xQR41 / V
781S, 781Mini, 787MS
782RA, 7860C-RS
Spinner
794, 794-TC
702, 725, 736, 741,
752, 754, xQR41 / V
781S, 781Mini, 787MS
Air pressure display Touchscreen Digital Analog Analog Digital Digital Digital Analog
Auto sequence mode — — — — — — — —
Cycle rate 1000Hz
1
280Hz / 150Hz >600/minute >400/minute >400/minute >400/minute >600/minute >400/minute
Digital time set
and display
P P P P P P
P P
Dual 24W
temperature control
— — — — — — — —
5-micron lter/
regulator
— — Included Included Included Included Included Included
I/O communication-PLC
P P
— — — — — —
I/O interface circuitry
P P P P P P
P P
Independent
multi-valve control
Single channel Single channel 4-channel control 2-channel control Single channel Single channel Single channel Single channel
Low air pressure
sensing
P
— < 4.1 bar (60 psi) < 4.1 bar (60 psi) < 4.1 bar (60 psi) < 4.1 bar (60 psi) < 4.1 bar (60 psi) < 4.1 bar (60 psi)
Nozzle air shutoff
delay
— — —
Adjustable
0 to 9.99 sec.
Adjustable
0 to 2.5 sec.
— —
Adjustable
0 to 9.99 sec.
On the y adjustability
P P P P P P
P P
Panel mount/panel
cutout size
142 x 133 mm
(5.6 x 5.25")
450 x 125 mm
(18 x 5")
183.6 x 51.6 mm (7.23
x 2.03")
183.6 x 51.6 mm (7.23
x 2.03")
226.3 x 68.8 mm (8.91
x 2.71")
226.3 x 68.8 mm (8.91
x 2.71")
142.9 x 68.8 mm (5.62
x 2.71")
205.4 x 68.8 mm (8.08
x 2.71")
Pre-dispense
time cycle delay
— —
P
— — — — —
Programmable
P
2
P P P P P
P P
Purge control
P P P P P P
P P
Spike & hold capability — — — — — — — —
Test cycle verication
P P P P P P
P P
P Applicable |
°
Optional | — Not applicable
1
With approved conditional settings
2
Programmable lockout
36
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Precision Dispensing Solutions
Expert Application
Testing
Features and Benets
• Testing by knowledgeable, dispensing experts
• Testing in EFD global labs and/or at customer facilities
• Testing with actual customer parts and assembly uids, or with EFD sample
test materials
• Testing with a range of recommended EFD solutions, including PICO and
pneumatic jetting valves and EFD automated dispensing robots
• Detailed test reports
• May include videotaped results
Nordson EFD offers a detailed process evaluation by experienced uid dispensing
experts at multiple EFD dispensing labs around the world.
EFD Global Application Labs are located in the USA, Brasil, the UK, Czech Republic,
France, Germany, Russia, Spain, China, Japan, Korea, and other countries for expert
help, fast response, and easy convenience.
Application testing is especially helpful to customers in selecting the appropriate PICO
or pneumatic jet valve components, to make sure the system meets the requirements
of your specic application.
For details or to request an appointment, contact EFD at info@nordsonefd.com
or go to www.nordsonefd.com/testing.
“Your technical assistance is formidable.
Your help in solving our problems with
the cyanoacrylate application was very
important to keep our production line
running correctly. Thank you.”
– Kodak
