35
CONTROLLER
FEATURES
VALVE CONTROLLERS
PICO Toµch / XP V200 8000 8040 7160RA 7194 7100 7140
Jet Valve Control Jet Valve Control Multi Valve Control
Multi Spray
Valve Control
Radial Spinner/
Spray Valve Control
Auger Valve Control Dispense Valve Control Spray Valve Control
Recommended valve(s) PICO Pµlse / XP
P-Jet,
P-Dot
702, 725, 736, 741,
752, 754, xQR41 / V
781S, 781Mini, 787MS
782RA, 7860C-RS
Spinner
794, 794-TC
702, 725, 736, 741,
752, 754, xQR41 / V
781S, 781Mini, 787MS
Air pressure display Touchscreen Digital Analog Analog Digital Digital Digital Analog
Auto sequence mode — — — — — — — —
Cycle rate 1000Hz
1
280Hz / 150Hz >600/minute >400/minute >400/minute >400/minute >600/minute >400/minute
Digital time set
and display
P P P P P P
P P
Dual 24W
temperature control
— — — — — — — —
5-micron lter/
regulator
— — Included Included Included Included Included Included
I/O communication-PLC
P P
— — — — — —
I/O interface circuitry
P P P P P P
P P
Independent
multi-valve control
Single channel Single channel 4-channel control 2-channel control Single channel Single channel Single channel Single channel
Low air pressure
sensing
P
— < 4.1 bar (60 psi) < 4.1 bar (60 psi) < 4.1 bar (60 psi) < 4.1 bar (60 psi) < 4.1 bar (60 psi) < 4.1 bar (60 psi)
Nozzle air shutoff
delay
— — —
Adjustable
0 to 9.99 sec.
Adjustable
0 to 2.5 sec.
— —
Adjustable
0 to 9.99 sec.
On the y adjustability
P P P P P P
P P
Panel mount/panel
cutout size
142 x 133 mm
(5.6 x 5.25")
450 x 125 mm
(18 x 5")
183.6 x 51.6 mm (7.23
x 2.03")
183.6 x 51.6 mm (7.23
x 2.03")
226.3 x 68.8 mm (8.91
x 2.71")
226.3 x 68.8 mm (8.91
x 2.71")
142.9 x 68.8 mm (5.62
x 2.71")
205.4 x 68.8 mm (8.08
x 2.71")
Pre-dispense
time cycle delay
— —
P
— — — — —
Programmable
P
2
P P P P P
P P
Purge control
P P P P P P
P P
Spike & hold capability — — — — — — — —
Test cycle verication
P P P P P P
P P
P Applicable |
°
Optional | — Not applicable
1
With approved conditional settings
2
Programmable lockout
36
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Precision Dispensing Solutions
Expert Application
Testing
Features and Benets
• Testing by knowledgeable, dispensing experts
• Testing in EFD global labs and/or at customer facilities
• Testing with actual customer parts and assembly uids, or with EFD sample
test materials
• Testing with a range of recommended EFD solutions, including PICO and
pneumatic jetting valves and EFD automated dispensing robots
• Detailed test reports
• May include videotaped results
Nordson EFD offers a detailed process evaluation by experienced uid dispensing
experts at multiple EFD dispensing labs around the world.
EFD Global Application Labs are located in the USA, Brasil, the UK, Czech Republic,
France, Germany, Russia, Spain, China, Japan, Korea, and other countries for expert
help, fast response, and easy convenience.
Application testing is especially helpful to customers in selecting the appropriate PICO
or pneumatic jet valve components, to make sure the system meets the requirements
of your specic application.
For details or to request an appointment, contact EFD at info@nordsonefd.com
or go to www.nordsonefd.com/testing.
“Your technical assistance is formidable.
Your help in solving our problems with
the cyanoacrylate application was very
important to keep our production line
running correctly. Thank you.”
– Kodak
37
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Valve Accessories
The BackPack
™
Valve Actuator maintains
constant pressure at the actuating air
inlet, for faster response time without
the risk of process variations due to a
uctuating plant air supply or different air
line lengths.
• High-speed cycle capability. Cycle
rates exceed 60–80Hz
• Actuation speed as low as
5–6 milliseconds
• Smaller deposit size capability due
to faster valve actuation speed
• Improves process variation for better
dot-to-dot consistency
BackPack Valve
Actuator
7361396 BackPack
BackPack is available preinstalled on new valves,
or can be ordered separately to retrofit existing
valves.
Needle Nozzle
Cleaning Station
The patent-pending Needle Nozzle
Cleaning Station is designed to automate
the cleaning of needle valve dispensing
tips and PICO / Liquidyn jet valve
nozzles.
• Easy to operate
• “Plug and play” into your existing
automated dispensing process
• Only requires compressed air
• Compatible with most uids
For use with:
xQR41 Series Valves
741 Series Valves
PICO Pµlse Contact Valves
Liquidyn Series Valves
7825249 Needle Nozzle Cleaning Station
Needle Nozzle Cleaning Station includes adapters
for use with PICO / Liquidyn nozzles and Optimum
stainless steel dispense tips.
For use with:
752V Series Valves
xQR41 Series Valves
741 Series Valves
www.nordsonefd.com/NNCS
www.nordsonefd.com/BackPackVideo
