42 Precision Jetting Valve Systems PICO / Liquidyn Nordson EFD jet valve systems offer unparalleled speed and accuracy in non-contact dispensing, even for your most challenging applications. Jetting, or non-contact dispe…
41
7021867
7007017
7021537
7021539
7021545
7016948
7016945
7007026
7007027
7021227
7021312
7021317
7014835
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
Valve Fittings / Tip Adapters
VALVE FITTINGS
Fitting Part # Description
Inlet tting assembly, ELB, 303SS
Polypropylene Y-tting for 1/8" ID tubing
Black nylon Y barb tting for 3.2 mm (1/8") ID tube
Polypropylene Y-tting for 3/32" ID tubing
Black plastic push-in tting for 4.0 mm (5/32") OD tube
VALVE TIP ADAPTERS
Adapter Part # Valve Material Description
725 Series Polypropylene Tip adapter 1/4 NPT, black
725 Series Nickel-plated brass Tip adapter 1/4 NPT
741MD-SS,
741V Series
Stainless steel Tip adapter 741V, 0.046"
741MD-SS,
741V Series
Polypropylene
SafetyLok collar for
741MD-SS, 741V Series
741MD-SS Stainless steel Tip adapter with retaining nut
750V-SS Acetal Tip adapter
751V Nylon Tip adapter
752V-UHSS Polypropylene Tip adapter, natural
42
Precision Jetting Valve Systems
PICO / Liquidyn
Nordson EFD jet valve systems offer unparalleled speed and
accuracy in non-contact dispensing, even for your most
challenging applications.
Jetting, or non-contact dispensing, allows manufacturers to
dispense small amounts of uids at faster speeds without
sacricing accuracy. The results include reduced waste,
rework, and rejects, and higher throughput yields.
About Piezo Technology
PICO
®
jet valves incorporate a piezoelectric actuator
composed of stacked ceramic coins that expand and
contract in response to changes in voltage supplied by the
PICO controller. The piezo actuator connects to a vertical
rod that mates with a tappet stem within a spring-energized
“jetting” cartridge. The tappet stem has a wear-resistant
ceramic sealing ball at its lower end.
When the valve is closed, the ball is seated in the valve
nozzle plate to prevent uid ow between cycles. The
unique precision engineering and machining of these critical
components create an exceptional dispensing valve with the
ability to apply precise, accurate micro-deposits of assembly
uid.
When voltage is applied to the actuator, the rod and cartridge
sealing ball are raised so that the pressurized uid can ow to
the nozzle. When the voltage is changed, the rod and tappet
stem sealing ball descend rapidly to “jet” the uid out of the
nozzle and onto the substrate.
Pneumatic Jetting
Liquidyn
®
pneumatic jet valves deliver precise, consistent
noncontact dispensing of low- to high-viscosity uids and
feature easily exchangeable dispensing nozzles to meet a
wide range of application requirements. Rigorously tested to
withstand highly-industrial environments, Liquidyn pneumatic
jet valves also feature a low cost of ownership.
43
www.nordsonefd.com info@nordsonefd.com USA & Canada 800-556-3484 Europe 00800 7001 7001 Asia +86 (21) 3866 9006
PICO Jetting Systems
Features and Benets
• Exchangeable, modular design for
greater congurability
• Tool-free latch allows fast, easy
serviceability and reduces downtime
• Capability to jet low- to high-viscosity
uids creats exibility to meet changing
needs
• Dispenses at up to 1000Hz
continuous, with up to 1500Hz
maximum bursts*
• Variable stroke for precise dispensing
control
• Optional PEEK wetted parts resist
curing from reactive adhesives
PICO Pμlse Jet Valve
7361283 PICO Pμlse Jet Valve HD
For heavy duty applications with cycle rates greater
than 250Hz.
PICO
Pµlse
®
modular jetting technology removes the barrier between speed and
accuracy. Even at max speed of 1000Hz continuous*, the PICO Pµlse non-contact
dispense valve provides industry-leading accuracy in deposit consistency and
placement for your most challenging applications.
Non-contact jet valve systems make it possible to apply uid in hard-to-access areas
or onto uneven or delicate substrates where a dispensing needle cannot be used.
www.nordsonefd.com/Pulse
“We are saving 2 to 4 hours on every
100 parts.”
– Grimes Aerospace
*With approved conditional settings.
Size: 22.0w x 120.0h x 75.0l mm (0.87w x 4.72h x 2.92l")
Weight: With cable: 524.0 g (18.5 oz)
Without cable: 362.0 g (12.8 oz)
Maximum uid pressure: 35.0 bar (500 psi)
Fluid inlet: M5
Mounting: M4 x 0.7
Fluid body: 303 stainless steel or PEEK*
Ball-and-seat: Ceramic
Heater body: Aluminum
Approvals: CE, UKCA, WEEE, TUV
Warranty: 1 year, limited
All stainless steel parts are passivated.
*Polyetheretherketone
Specications
For use with
• Adhesives & UV-cure Adhesives
• Conductive Epoxies
• Greases & Oils
• Hydrous Solutions
• Liquid Polymers
• Organic Solvents
• Underlls
