Translation Formats

B-34 AutoSite User Manual

JEDEC Format, Codes 91 and 92

Introduction

The JEDEC (Joint Electron Device Engineering Council) format is used to

transfer fuse and test vector data between the programmer and a host

computer. Code 91 is full format and includes all the data fields (such as

note and test fields) described on the following pages. Code 92 is the

Kernel, or shorter, format. The JEDEC Kernel format includes only the

minimum information needed for the programming; it does not, for

example, include information fields or test vector fields. Prior to

transferring a JEDEC file, the appropriate Logic device must be selected.

JEDEC’s legal character set consists of all the printable ASCII characters

and four control characters. The four allowable control characters are

STX, ETX, CR (RETURN), and LF (line feed). Other control characters,

such as ESC or BREAK, should not be used.

Note: This is Data I/O Corporation’s implementation of JEDEC Standard 3A.

For a copy of the strict standard, write to:

Electronic Industries Association

Engineering Department

2001 Eye Street NW

Washington, D.C. 20006

BNF Rules and

Standard Definitions

The Backus-Naur Form (BNF) is used in the description here to define the

syntax of the JEDEC format. BNF is a shorthand notation that follows

these rules:

:: = denotes “is defined as.”

Characters enclosed by single quotes are literals (required).

Angle brackets enclose identifiers.

Square brackets enclose optional items.

Braces {} enclose a repeated item. The item may appear zero or more

times.

Vertical bars indicate a choice between items.

Repeat counts are given by a :n suffix. For example, a 6-digit number

would be defined as:

<number> :: = <digit>:6

Translation Formats

AutoSite User Manual B-35

For example, in words the definition of a person's name reads:

The full name consists of an optional title followed by a first name, a

middle name, and a last name. The person may not have a middle name,

or may have several middle names. The titles consist of: Mr., Mrs., Ms.,

Miss, and Dr.

The BNF definition for a person's name is:

<title> :: = ‘Mr.’ | ‘Mrs.’ | ‘Ms.’ | ‘Miss’ | ‘Dr.’

The following standard definitions are used throughout the rest of this

document:

<digit> :: = ‘0’ | ‘1’ | ‘2’ | ‘3’ | ‘4’ | ‘5’ | ‘6’ | ‘7’ | ‘8’ | ‘9’

<hex-digit> :: = <digit> | ‘A’ | ‘B’ | ‘C’ | ‘D’ | ‘E’ | ‘F’

<binary-digit> :: = ‘0’ | ‘1’

<number> :: = <digit> {<digit>}

<delimiter> :: = <del> {<del>}

<space> :: = <ASCII 20 hex> | “

<valid character> :: = <printable character> | <carriage return> |

<field character> :: = <ASCII 20 hex ... 29 hex> | <ASCII 2B hex ... 7E

hex> | <carriage return> | <line feed>

Translation Formats

B-36 AutoSite User Manual

The Design Specification

Field

<design spec> ::= {<field character>}’*’

The first field sent in a JEDEC transmission is the design specification.

Both the full and kernel JEDEC formats accept the design specification

field. This field is mandatory and does not have an identifier (such as an

asterisk) signaling its beginning. The design specification field consists of

general device information. It could, for example, consist of the following

information: your name, your company's name, the date, the device name

and manufacturer, design revision level, etc. This field is terminated by

an asterisk character. Examine the sample transmission shown on the

next page of this description—the first three lines of the file comprise the

design specification field. The programmer ignores the contents of this

field for downloads and places “Data I/O” in this field for upload

operations.

Note: You do not need to send any information in this field if you do not wish to;

a blank field, consisting of the terminating asterisk, is a valid design

specification field.

The Transmission

Checksum Field

<xmit checksum> ::= <hex digit>:4

The transmission checksum is the last value sent in a JEDEC

transmission. The full JEDEC format requires the transmission checksum.

The checksum is a 16-bit value, sent as a 4-digit hex number, and is the

sum of all the ASCII characters transmitted between (and including) the

STX and ETX. The parity bit is excluded in the calculation of the

transmission checksum.

Some computer systems do not allow you to control what characters are

sent, especially at the end of a line. You should set up the equipment so

that it will accept a dummy value of 0000 as a valid checksum. This zero

checksum is a way of disabling the transmission checksum while still

keeping within the JEDEC format rules.
