Component barcode scanner 5
On each side of the middle console there is a bracket that holds the Datalogic DL 910 component
barcode scanner. The barcode scanner enables the components to be set up and topped up
quickly and reliably.
5.2.3 Ergonomic arrangement of the controls
Figure 5.2 - 1 on page 295 provides an overview of the position of the controls. They are subdi-
vided into the following groups:
Operator panel on the right-hand side (pneumatic unit) of the center console with 5
– LCD touchscreen
– Keyboard with trackball
– Start button, stop button
Operator panel on the left-hand side (power supply unit) of the center console with 5
– LCD touchscreen
– Keyboard with trackball
– Component counter
– Start button
– Stop button
– Main power switch
Input / output side of the PCB conveyor with 5
– EMERGENCY STOP button
– Start button, stop button
– Button for docking the component trolley in and out
5.2.3.1 Controls on the machine's operator panels
The two operator panel have identical control functions.
Monitor, keyboard, start and stop buttons 5
There is a monitor and a keyboard on both sides of the machine.
Tasks on the machine User manual SIPLACE X-series
Controls and displays From software version SR.70x.xx 01/2011 EN edition
298
The start and stop buttons are located beneath the keyboard. The on-screen dialog will occasion-
ally prompt you to activate certain actions using buttons, and this arrangement will make it easier
for you both to activate and to interactively control these actions.
Main power switch 5
The main power switch is part of the power module. It is located on the left-hand operator panel
viewed in the direction of PCB transport. It is located here because it is only needed for servicing
and preventive maintenance work and is therefore not subject to frequent use.
5.2.3.2 Controls on the input and output sides of the machine
The controls on the input and output sides of the machine perform identical functions.
Emergency stop buttons, start and stop buttons 5
There is an emergency stop button and start and stop buttons on both the input and output sides
of the PCB conveyor. This arrangement was adopted for the buttons because it enables them to
be reached quickly and easily from any position.
User manual SIPLACE X-series Tasks on the machine
From software version SR.70x.xx 01/2011 EN edition Switch on the SIPLACE line
299
5.3 Switch on the SIPLACE line
5.3.1 Start the SIPLACE Pro Line Control GUI program
On the line computer, start SIPLACE Pro Line Control GUI
from the Windows Start menu
Start --> Programs --> SIPLACE Pro --> LCGUI
or
by clicking the icon on the desktop.
Enter your user data.
The system then connects to the SIPLACE Pro server and opens the GUI.
5.3.2 Points to note before you switch on the stations
CAUTION
Before you switch on the stations, please carry out the steps described below. 5
Check that the stations are connected to the power and compressed air supplies.
Visually inspect the stations. In particular, make sure that there are no obstacles in the gantry
traversing range.
Make sure that the Z-axes of all the heads are in their top end positions.
