(Green) Starts the context-sensitive help for the current view. All the controls in the view are briefly

explained.

(Red) Starts the help system that lists possible causes of the current error and suggests ways to

eliminate them (see section 5.6.1

, page 313).

Opens a dialog box containing the source of the error, the error message text and the date and

time at which the error occurred (see section 5.6.1

, page 313). You can also call up help about

the current error from here.

Clears the currently-displayed error from the status field.

5.5.2 Display and processing area

This area contains the buttons for setting / starting functions, general information about the PCB,

set-up, batch and other notes.

Animated objects identified by different colors are used to display operations or statuses (e.g. pro-

cessing, location empty, etc.).

The "Production" view (main view) signals certain operating statuses (processing, error, etc.).

Pause processing. Pauses the current placement process.

Resume processing. Starts or resumes placement of the PCBs.

Progress bar

Displays the how far the placement process has progressed for each PCB.

PCB in progress

The PCB is in the system and is being processed. The PCB symbol appears dark green in the

form of a button.

Processing of PCB canceled

If processing was cancel, the PCB symbol turns red.

PCB must be checked

If the PCB is on the output belt and the status of the PCB has to be checked by the operator, the

PCB symbol turns yellow.

User manual SIPLACE X-series Tasks on the machine

From software version SR.70x.xx 01/2011 EN edition The user interface

307

5.5.3 Toolbar

The toolbar contains buttons for the main station software functions.

This allows you to switch the user interface to other views and to use other functions from these

views (see section 5.5.5

, page 310).

Fig. 5.5 - 2 Toolbar

The buttons vary according to the configuration and which operator level is set. Some views are

only available at the higher operator levels.

The following table briefly describes the buttons and their main functions.

Symbol View Description

Basic production

(main view)

Displays the machine status for the -tasks most frequently carried

out during basic production.

Displays the operating statuses, see section 5.5.2

, page 306.

Displays locations, set-up name, batch name, changes made to the

configuration and additional options.

Feeders, compo-

nents and noz-

zles

The set-up can be called for each of the 4 locations individually.

For checking and setting up feeders, components and nozzles.

For teaching component shapes and component pocket shapes.

Displays the fill level.

PCBs Displays the PCB and placement positions list.

For checking and setting up the PCBs and components.

For teaching fiducials.

Messages Displays messages about current and previous events. There are

different types of message. A table can be called up for track errors,

conveyor errors, machine errors, general errors and concatenated

error messages (see section 5.6

, page 312).

Statistics Displays statistics about output, quality and rejected materials.

Displays the output of the machines and PCBs.

Starts the OIS (Operator Information System), for further informa-

tion, see the OIS documentation.

Settings Contains all the settings and options.

For setting the operator level and language of the user interface.

For displaying and changing machine settings, user settings, ma-

chine options and software options, see section 5.5.5

, page 310.

Tasks on the machine User manual SIPLACE X-series

The user interface From software version SR.70x.xx 01/2011 EN edition

308

5.5.4 Using the station software within the views

Most of the views that are called from the toolbar (see section 5.5.3, page 307) have an additional

vertical toolbar for sub-views and functions on the right-hand side of the user interface.

NOTE

You will find a detailed description of the individual functions in the online help. 5

Example: "Feeders, components and nozzles" view

 Click "Feeders, components and nozzles" on the toolbar.

The following view opens:

Live image during

placement

Displays the individual camera live images.

Only available at "Advanced production" operator level or higher:

displays and saves the vision dumps.

Check sensors

and functions

Contains information and functions for testing and diagnostics.

For setting the response to the machine Start button.

Only available at "Advanced production" operator level or higher:

for testing the complete reference run and functions of the C&P20A

head.

Single Functions and continuous runs. Each gantry is activated

separately.

Service Service tools.

Only available at "Machine service" operator level or higher.

For setting up and calibrating SIPLACE placement machine, down-

loading embedded software versions, calibrating and configuring

the complete machine.

Symbol View Description
