User manual SIPLACE X-series Operational safety
From software version SR.70x.xx 01/2011 EN edition Safety instructions
37
2 Operational safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This user manual contains notes that must be observed to guarantee your personal safety and to
avoid damage to equipment. These notes are highlighted by warning triangles and are indicated
as follows according to the level of risk:
DANGER or
as used in this user manual means that death, severe injury or considerable damage to equipment
will occur if the danger instructions are not followed.
WARNING or
as used in this user manual means that death, severe injury or considerable damage to equipment
may occur if the warning instructions are not followed.
CAUTION or
as used in this user manual means that slight injury or damage to equipment may occur if the cau-
tion instructions are not followed.
PLEASE NOTE
as used in this user manual provides information on the product or indicates a part of the user
manual that requires particular attention.
2.1.2 Qualified personnel
Qualified or adequately trained personnel means that these people are familiar with the setting up,
operation and preventive maintenance of placement machines and add-on devices and are suit-
ably qualified, e.g.
– have been trained, instructed or authorized to switch on and off, isolate, earth and identify
electrical circuits and system components in accordance with normal safety standards.
– have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-
cordance with normal safety standards.
– have received first aid training.
Operational safety User manual SIPLACE X-series
Safety instructions From software version SR.70x.xx 01/2011 EN edition
38
2.1.3 Important notes on operational safety
The following points MUST be observed in order to maintain operational safety:
2.1.3.1 General
→ The operational safety of SMD placement machines can be guaranteed only if the system is
used as prescribed and in accordance with the instructions in the user/preventive mainte-
nance manuals.
→ Always follow any safety regulations specific to your country.
→ Make sure that the warning labels are always clearly identifiable and always easily readable.
→ Replace any damaged warning or notice labels. Replace any labels that are missing.
→ The machine key for releasing the covers on the machine must be kept in a safe place where
it is only accessible to qualified personnel.
PLEASE NOTE
The machine owner, and only the machine owner, is responsible for the safekeeping of the
machine key and for ensuring that it is handed over to authorized persons. 2
→ If it is necessary to work on the machine and you do not have adequately trained personnel
within your operation, always call in a service engineer from ASM Assembly Systems GmbH
& Co. KG! ASM Assembly Systems GmbH & Co. KG will not accept liability for any damage
or consequential damage that is the result of incorrect work.
→ If particularly hazardous situations are identified while the machine is in use, the machine
owner must immediately notify the manufacturer in writing so that appropriate action can be
taken to reduce the potential danger.
WARNING
In spite of all the safety precautions taken by the manufacturer, failure to use the system as pre-
scribed can result in severe physical injury (e.g. from the moving gantry or lifting table) and/or con-
siderable damage to equipment. For the machine to be safe, it must be used correctly by qualified
personnel and all warnings must be observed. Some work on the machine (e.g. setting up) re-
quires training that goes beyond the scope of this manual. 2
User manual SIPLACE X-series Operational safety
From software version SR.70x.xx 01/2011 EN edition Safety instructions
39
2.1.3.2 Safety of operators and other persons
→ Machine operators must only carry out work for which they have been adequately trained and
with which they are totally familiar.
→ NEVER open one of the protective covers if you are not totally familiar with the use and func-
tioning of the machine! Do not open the protective covers during operation unless you are told
to do so in this manual or in the station software dialog.
→ NEVER place your head or arms in the gantry and lifting table traveling range while the station
is switched on!
→ For your own safety, wear work clothes that conform to the guidelines of the professional as-
sociation, i.e. no wide sleeves etc.
→ Reduce the risks by not wearing scarves, chains or ties at your work post.
→ People with long hair must wear a protective head covering.
WARNING 2
The system is electrically driven. When electrical devices are in use, certain parts carry dangerous
voltage levels.
→ Switch off at the main switch and disconnect the placement machine from the power supply
before carrying out any work on live components.
→ Lock the systems as described in Section 2.10
, page 94.
There is a risk of death, severe injury and/or considerable damage to equipment if these instruc-
tions are not followed.
2.1.3.3 Safety of plant and equipment
→ Never make changes, however minor, unless you are totally aware of the effect they will have
on the overall functioning of the system.
→ The stations must always be set up, retooled and maintained by appropriately trained person-
nel.
→ Do not make modifications to the safety equipment. In particular, NEVER deactivate circuit-
breakers or remove safety devices.
2.1.4 Safety instructions for laser units
Permission to operate components that are classified as lasers is withdrawn if
– mechanical damage to the unit is observed, or
– any work is done on the mechanical or electrical parts of the unit. Even damaged or miss-
ing screw locking paint on laser components (e.g. cover plates, fasteners, adjusting po-
tentiometer) counts as work.
