From software version SR.70x.xx 01/2011 EN edition Laser classification
61
2.3.3 Laser class 2
The following modules are assigned to laser class 2:
– Laser light barrier, placement area 1 in the PCB conveyor
– Laser light barrier, placement area 2 in the PCB conveyor
– PCB barcode scanner
– Component sensor on the SpeedStar
– Component sensor on the MultiStar
2
2.3.4 Laser class 3B
The 3D coplanarity sensor is assigned to laser class 3B.
2
PLEASE NOTE: 2
The entire machine is classified as laser class 2 if the coplanarity 3D laser module option is
installed.
2
Laser radiation
Do not look into beam!
2
Laser radiation
Do not expose to beam!
2
Laser radiation
Do not look into beam!
Operational safety User manual SIPLACE X-series
Safety instructions for transporting the machine From software version SR.70x.xx 01/2011 EN edition
62
2.4 Safety instructions for transporting the machine
2
Use a fork-lift truck with the following specification to carry the machine:
Fork length: min. 1800 mm
Carrying power: min. 6000 kg
Clear width between forks: min. 350 mm 2
WARNING
RISK OF TIPPING 2
If the required specification cannot be applied to the fork-lift, there is a risk that the fork-lift will tip
over when carrying the machine.
Transporting the machine is described in chapter 4, Section 4.1, page 209.
User manual SIPLACE X-series Operational safety
From software version SR.70x.xx 01/2011 EN edition Safety instructions for operating the machine
63
2.5 Safety instructions for operating the machine
2.5.1 Safety instructions for closing the protective covers
To -prevent any risk of injury when the protective covers on the machine are closed, the owner
must instruct his operators to use the protective covers exactly as specified in the following in-
structions.
CAUTION
RISK OF CRUSHING HANDS
IF THE PROTECTIVE COVERS ARE NOT CLOSED CORRECTLY 2
2
Fig. 2.5 - 1 Safety instructions for closing the protective covers
(1) Protective covers
(2) Grab handles
(3) Cover flaps over the PCB conveyor
(4) Warning strips
