4 23 22 21 9 16 17 18 20 17 6 2 3 17 17 17 7 21 16 20 21 11 14 16 16 26 12 15 25 27 21 13 1 24 21 10 8 19 13 5 No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date 1 KLF-M741J-00 BASE,V AL VE 1 2 KLF-M741L…
5
5
Head (FL)
Head
KMB-100-1607
27
26
31
6
8
8
33
32
4
19
21
5
4
5
21
29
7
20
20
6
30
29
15
3
11
18
9
10
18
22
17
14
13
2
12
12
15
19
16
28
28
28
24
23
27
26
34
1
25
23
16
35
36
37
35
38
36
37
38
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M7411-01 PLATE,BASE 1
2 KLF-M741P-00 COVER,HEAD 1
3 KLF-M741R-00 BLOCK,HEAD 1
4 KLF-M742C-00 SPRING,RETURN 2
5 KLF-M742K-00 GUIDE, SPRING 2
6 KLF-M742R-00 BRKT.,CABLE 2
7 KLF-M74C1-00 COVER,CABLE 1
8 KLF-M74Y0-00 LABEL,HEAD SERIAL 2
9 KLF-M7143-01 KEY,PARALLEL 1
10 90112-02J008 BOLT HEX.SOCKET HEAD 4
11 90990-01J038 BOLT,HEX.SOCKET HEAD 2
12 90990-01J058 BOLT,HEX.SOCKET HEAD 8
13 91312-03008 BOLT HEX.SOCKET HEAD 2 M3X8
14 91312-03010 BOLT HEX.SOCKET HEAD 2 M3X10
15 91312-04014 BOLT HEX.SOCKET HEAD 4 M4X14
16 91312-04025 BOLT HEX.SOCKET HEAD 4 M4X25
17 91312-05014 BOLT HEX.SOCKET HEAD 4 M5X14
18 91312-05018 BOLT HEX.SOCKET HEAD 8 M5X18
19 91317-04008 BOLT HEX.SOCKET HEAD 2 M4X8
20 92012-04008 BOLT,BUTTON HEAD 4 M4X8
21 92017-04008 BOLT,BUTTON HEAD 4 M4X8
22 99480-05010 PIN,PARALLEL 4
23 KLF-M7451-A1 VALVE,ASSY. 2
24 KLF-M654C-00 SENSOR PRESS. ASSY 1
25 $PF-M3 PLUG 1
26 $TS6-01M JOINT 2
27 $TSH6-M5M JOINT 4
28 $AUT6M JOINT 4
29 99480-04012 PIN,PARALLEL 2
30 KLF-M74S0-00 Z1 AXIS ASSY. 1
31 KLF-M74S0-10 Z2 AXIS ASSY. 1
32 KLF-M74R0-00 R1 AXIS ASSY. 1
33 KLF-M74R0-10 R2 AXIS ASSY. 1
34 KLF-M74C0-00 SERVO I/O BOX ASSY. 1
35 KLF-M7153-00 VALVE 6 Spare
36 KLF-M7156-00 FILTER 2 Spare
37 90166-02JA04 SCREW PAN HEAD 4 Spare
38 KLF-M7155-00 FILTER JOINT 2 Spare
4
23
22
21
9
16
17
18
20
17
6
2
3
17
17
17
7
21
16
20
21
11
14
16
16
26
12
15
25
27
21
13
1
24
21
10
8
19
13
5
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M741J-00 BASE,VALVE 1
2 KLF-M741L-00 STAY,BASE 1
3 KLF-M741M-00 STAY,COVER 1
4 KLF-M741N-00 BRACKET,CONNECTOR 1
5 KLF-M741V-00 STAY,BKT. 1
6 KLF-M741W-00 BRKT,CABLE Z MOTOR 1
7 KLA-M5802-48 HEAD SERVO UNIT ASSY 1
8 KLF-M6185-00 FAN MOTOR ASSY. 1
9 KLF-M7191-01 BOX,SERVO BRD. 1
10 KLF-M7196-00 BASE,FAN MOTOR 1
11 KLF-M71C6-00 BRACKET,SERVO BOX 1
12 KLF-M71C7-00 BRACKET,JOINT 1
13 KLF-M71CB-00 PLATE,NUT 2
14 KLF-M71CE-00 CLAMP,CONNECTOR 1
15 90990-23J030 GROMMET 5
16 91312-03006 BOLT HEX.SOCKET HEAD 8 M3X6
17 91312-03008 BOLT HEX.SOCKET HEAD 9 M3X8
18 91312-03010 BOLT HEX.SOCKET HEAD 2 M3X10
19 91312-03020 BOLT,HEX.SOCKET HEAD 4 M3X20
20 91312-04006 BOLT HEX.SOCKET HEAD 4 M4X6
21 91312-04008 BOLT HEX.SOCKET HEAD 9 M4X8
22 92012-04006 BOLT, BUTTON HEAD 2 M4X6
23 92012-04008 BOLT,BUTTON HEAD 2 M4X8
24 $NK-3N NYLON CLIP 1
25 $TS6-01 JOINT 5
26 $TSM8-01 JOINT 5
27 $UP6 PLUG 1
6
5
Servo - I/O BOX (FL)
Head
KMB-100-1607
22
16
22
15
8
2
22
21
18
14
13
11
12
3
27
21
29
24
17
28
21
20
9
7
23
31
26
26
1
10
19
4
5
30
6
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M7412-00 PLATE,HEAD 1
2 KLF-M7414-00 HOLDER,MOTOR Z 1
3 KLF-M7421-01 BALL SCREW 1
4 KLF-M7422-00 GUIDE,Z AXIS 1
5 KLF-M7423-00 BLOCK,SCREW 1
6 KLF-M742A-00 DAMPER 1 1
7 KLF-M742B-00 DAMPER 2 1
8 KLF-M748B-01 COUPLING 1
9 KJX-M7C15-00 HOLDER,BEARING 1
10 KJX-M7C2C-00 PLATE,HOLDER BRG. 1
11 KLH-M7C2A-00 BEARING 1
12 KLH-M7C2G-00 PLATE,BEARING 1
13 KLH-M7C2N-00 LOCK NUT,SCREW 1
14 KLH-M7C2P-00 SPACER 2
15 90K2F-032003 AC SERVO MOTOR Z1 1 Z1
16 90K2F-032004 AC SERVO MOTOR Z2 1 Z2
17 90933-02J624 BEARING 1
18 90990-02J004 SET SCREW 2
19 91312-03005 BOLT HEX.SOCKET HEAD 3 M3X5
20 91312-03008 BOLT HEX.SOCKET HEAD 6 M3X8
21 91312-03010 BOLT HEX.SOCKET HEAD 8 M3X10
22 91312-03014 BOLT,HEX.SOCKET HEAD 8 M3X14
23 91312-03018 BOLT HEX.SOCKET HEAD 2 M3X18
24 91312-03020 BOLT,HEX.SOCKET HEAD 4 M3X20
26 91312-04014 BOLT HEX.SOCKET HEAD 4 M4X14
27 91312-04020 BOLT HEX.SOCKET HEAD 4 M4X20
28 99009-04400 CIRCLIP 1
29 99480-03008 PIN,PARALLEL 2
30 99480-04010 PIN PARALLEL: 4X10 4
31 99480-04012 PIN,PARALLEL 2
7
5
Z-axis Assy (FL)
Head
KMB-100-1607
